TABLE II: DID PANEL FAULT CODES (Cont.)
EVENT
DESCRIPTION
EVENT
RESTRICTION
DETECTION
INFORMATION
EVENT
NUMBER
Limp
Possible
Lockout
Limit
007
INVERTER COMMUNICATION
FAILED
No power Lost Communication with an inverter. Yes 3
:01 inv 1 No power Lost Communication with an inverter.
:02 inv 2 No power Lost Communication with an inverter.
008 DC LINK OVERLOAD No power
DC link voltage exceeds limit for a
sufficient time.
N/A 3
:01 not in retard No power
Occurs while not in retard, exceeds
propel voltage limit.
:02 in retard No power
Occurs while in retard, exceeds retard
voltage limit.
:03 instantaneous No power
Occurs istantaneously in propel or
retard, exceeds link voltage limit.
009 ALT FIELD OVERCURRENT No propel Alternator field current exceeds limit. N/A 3
:01 with persistence No propel Exceeds current limit over time.
:02 no persistence No propel
Exceeds current limit with no
persistence.
011 RETARD LEVER BAD No propel Incorrect input from retard lever. N/A 3
:01 voltage too high No propel Incorrect input from retard lever.
:02 voltage too low No propel Incorrect input from retard lever.
012 RETARD PEDAL BAD No propel Incorrect input from retard pedal N/A 3
:01 voltage too high No propel Incorrect input from retard pedal
:02 voltage too low No propel Incorrect input from retard pedal
013 LINKV ABOVE MIDVOLT No power Incorrect link volts
014 SENSOR FAULT No propel Incorrect input from a sensor.
:01 alt field amps No propel Incorrect input from a sensor.
:02 link amps No propel Incorrect input from a sensor.
:03 load box amps No propel Incorrect input from a sensor.
:04 3 phase alt volts No propel Incorrect input from a sensor.
:05 alt field volts No propel Incorrect input from a sensor.
:10 PSC link volts No propel Incorrect input from a sensor.
:11 inv1 link volts No propel Incorrect input from a sensor.
:12 inv2 link volts No propel Incorrect input from a sensor.
:21 blower 1 amps No propel Incorrect input from a sensor.
:22 blower 2 amps No propel Incorrect input from a sensor.
015 ANALOG CARD No propel Problem occurred in the analog card. N/A 3
:01 gnd fault No propel Problem occurred in the analog card.
:02 gainchk No propel Problem occurred in the analog card.
:03 ground fault current No propel Problem occurred in the analog card.
:04 ATOC ma No propel Problem occurred in the analog card.
E02014 3/01 Electrical Propulsion System Components E2-7
