CHECK-OUT PROCEDURE
HYDRAULIC BRAKE SYSTEM DATA SHEET
STEP 24
Brake lock degradation switch actuation pressure.
STEP 27 Rear brake pressure with brake lock applied.
Failure Modes Check-out
STEP 32 Low accumulator pressure after 2 minutes.
STEP 33 Pressure when warning systems actuate (front brakes).
Pressure at which auto apply actuates.
STEP 36 Pressure when warning systems actuate (rear brakes).
Pressure at which auto apply actuates.
STEP 40 Number of brake applications before auto apply actuates.
STEP 45 Front brake pressure at which differential switch actuates low brake
pressure buzzer and lamp.
STEP 51 Rear brake pressure at which differential switch actuates low brake
pressure buzzer and lamp.
Name of Technician or Inspector Performing Check-Out ...............................................................
J4-14 Brake Circuit Checkout J04025
