Global
P0
P1 P2 P3 P4 P5 P6
121
2–1: Controller
2–1a: Damper/Assignable Foot Switch, Pedal
Foot Switch Assign [Off...Cue Repeat Control]
Select the function that will be controlled by a pedal switch
(PS-1 option [sold separately]) connected to the rear panel
ASSIGNABLE SWITCH jack (
☞“Foot Switch Assign List”).
Foot Pedal Assign [Off...MFX Send 2(CC#91)]
Select the function that will be controlled by a foot volume
pedal (XVP-10 or EXP-2 option [sold separately]) connected
to the rear panel ASSIGNABLE PEDAL jack (
☞“Foot Pedal
Assign List”).
Damper Polarity [–, +]
Set this to match the polarity of the damper pedal connected
to the rear panel DAMPER jack.
If a Korg DS-1H (sold separately) damper pedal is con-
nected, the pedal switch polarity will be (↓), so select “–” for
this setting. If you have connected a damper pedal with a
positive (↑) polarity, select “+” for this setting. (↓ is open-
type, ↑ is closed-type.) If the polarity does not match, oper-
ating the damper pedal will not produce the correct result. If
no damper pedal is connected, set this to “–.”
Foot Switch Polarity [–, +]
Set this to match the polarity of the pedal switch connected
to the rear panel ASSIGNABLE SWITCH jack.
If a Korg PS-1 (sold separately) pedal switch is connected,
the pedal switch polarity will be (↓), so select “–” for this set-
ting. If you have connected a pedal switch with a positive
(↑) polarity, select “+” for this setting. (↓ is open-type, ↑ is
closed-type.) If the polarity does not match, operating the
pedal switch will not produce the correct result. If no pedal
switch is connected, set this to “–.”
3–1: User Scale
Here you can create sixteen User Octave Scales and one User
All Notes Scale. The user scales you create here can be
selected in the Program P1: Program Basic tab, the Combina-
tion/Sequencer P2: Other tab, or the Song Play P1: Status/
Scale tab.
If you wish to keep an edited user scale after the power
is turned off, be sure to write (save) your settings.
This data is written by the “Write Global Setting” page
menu command. Alternatively, you can press the front
panel [REC/WRITE] key to access the Write Global Set-
ting dialog box, and press the OK button to write the
edited data.
3–1a: User Octave Scale
User Octave Scale Type [User Octave Scale 00...15]
Tune [–99…+99]
Make pitch settings for each note in the octave.
When you adjust the pitch of each note in the octave (C–B)
in one-cent steps, your settings will be applied to all octaves.
This adjustment is relative to equal temperament.
A setting of –99 lowers the pitch approximately a semitone
below normal pitch.
A setting of +99 raises the pitch approximately a semitone
above normal pitch.
3–1b: User All Notes Scale
Tune [–99…+99]
Make independent pitch settings for each of the 128 notes.
Use the horizontal scroll bar to move to the desired located
of the keyboard, and adjust the pitch of each of the 128 notes
(C–1 – G9) in one-cent steps. This adjustment is relative to
equal temperament.
A setting of –99 lowers the pitch approximately a semitone
below normal pitch.
A setting of +99 raises the pitch approximately a semitone
above normal pitch.
By executing the “3–1A: Copy Scale” page menu command,
you can copy the settings of the preset Stretch scale.
The note can also be selected by holding down the
[ENTER] key and playing a note on the keyboard.
Global P2: Controller
0–1A
2–1a
Global P3: User Scale
3–1
3–1a
3–1b
