Program
P0
P1 P2 P3 P4 P5 P7 P8 P9
7
Transpose [–12…+12]
This adjusts the location of the instruments in the selected
drum kit. Unless you need to change this, leave it at 0.
Tune [–1200…+1200]
This adjusts the pitch in one-cent units.
The pitch of each drum kit can be adjusted in Global P5:
Drum kit.
Delay (Delay Time) [0ms…5000ms, KeyOff]
This specifies a delay time from note-on until the sound will
begin.
With a setting of KeyOff, the sound will begin when note-
off occurs. In this case, set the “Amp EG” (4–3a) parameter
“Sustain” to 0.
▼ 1–2: Page Menu Command
1–2A: Sample Parameters
This command lets you adjust the sample playback level,
cutoff, resonance, pitch, attack, and decay for each index of a
RAM multisample. This command is available when the
“Oscillator Mode” (1–1a) is Single or Double, and you have
selected either the “Bank” (RAM)” or “Multisample Select”
edit cell of either the High or Low sample of OSC1 Multi
Sample or OSC2 Multi Sample. The setting will apply to the
selected multisample. The setting will also be used when
that multisample is selected by another oscillator or pro-
gram.
1 Select this command to open the following dialog box.
2 Index: Specify the index for which you wish to make set-
tings. The number following “/” is the total number of
indexes in the selected multisample.
Sample: indicates the sample number and name for the
index.
3 For each index, you can make the following settings.
Level: Adjust the volume. Relative to the settings of
“Lvl” (1–2a) and “Amp Level” (4–1a, 4–4), negative (–)
values will decrease the levels, and positive (+) values
will increase the levels. A setting of +99 will double the
volume, and at a setting of –99 there will be no sound.
This parameter is linked to the “Level” (Sampling P3: 3–
1b). The value that was specified in Sampling mode will
be displayed here.
Cutoff: Adjust the filter cutoff. This adjustment will be
added to the value specified for “(Filter A) Frequency”
(3–1b, 3–5) of Filter 1 and 2.
Resonance: Adjust the resonance level of the filter. This
adjustment will be added to the value specified for “(Fil-
ter A) Resonance” (3–1b, 3–5) of Filter 1 and 2.
Pitch: Adjust the playback pitch in one-cent steps. A set-
ting of +12.00 raises the pitch one octave, and a setting of
–12.00 will lower the pitch one octave. This parameter is
linked with the Sampling P3: Multi Sample parameter
“Pitch” (Sampling P3: 3–1b). The value that was specified
in Sampling mode will be displayed here.
Attack: Adjust the attack times of the filter EG and amp
EG. This adjustment will be added to the “(Time) Attack”
of “Filter 1 EG,” “Filter 2 EG,” “Amp 1 EG,” and “Amp 2
EG” (3–4a, 3–8, 4–3a, 4–6).
Decay: Adjust the decay times of the filter EG and amp
EG. This adjustment will be added to the “(Time) Decay”
of “Filter 1 EG,” “Filter 2 EG,” “Amp 1 EG,” and “Amp 2
EG” (3–4a, 3–8, 4–3a, 4–6).
4 Press the Done button to execute, and close the dialog
box.
Please be aware that the Compare function is not avail-
able for this command.
1–3: Velo. Zone (Velocity Zone)
Here you can specify the velocity ranges for which oscilla-
tors 1 and 2 will sound. In conjunction with the “Velocity
M.Sample SW Lo → Hi” (1–2c) settings, these settings will
determine how velocity will switch between the High and
Low multisamples of the OSC1 Multisample and the OSC2
Multisample, and the range in which a drum kit will sound.
It is not possible to set the Bottom Velocity greater than
the Top Velocity, nor the Top Velocity less than the Bot-
tom Velocity.
1–3a: OSC 1/2 Velocity Zone
OSC1 Top [001...127]
Set the maximum velocity value that will sound oscillator 1.
OSC1 Bottom [001...127]
Set the minimum velocity value that will sound oscillator 1.
OSC2 Top [001...127]
Set the maximum velocity value that will sound oscillator 2.
OSC2 Bottom [001...127]
Set the minimum velocity value that will sound oscillator 2.
You can also input a value by playing a note on the key-
board while you hold down the [ENTER] key.
▼ 1–3: Page Menu Command
☞ “0–1A: Write Program,” “1–1A: Copy Oscillator,” and “1–
1B: Swap Oscillator.”
0–1A
1–1A
1–1B
1–2A
1–3
1–3a
