Korg TRITON proX User Manual

204
097: Early Reflections
This early reflection effect has more precise early reflections
with twice the maximum length of a normal-size effect
(Fx:041). You can create a very smooth and dense sound.
098: L/C/R Long Delay
This multitap delay outputs three Tap signals to left, right and
center respectively. You can set a maximum of 2,730msec for
the delay time.
099: St/Cross Long Dly
(Stereo/Cross Long Delay)
This is a stereo delay, and can by used as a cross-feedback
delay effect in which the delay sounds cross over between left
and right by changing the feedback routing. You can set a
maximum of 1,360msec for the delay time.
a
Type Sharp, Loose, Modulated, Reverse
Selects the decay curve for the early reflection
☞ Fx:041
b
ER Time [msec]
Sets the time length of early reflection
10...1600msec
c
Pre Delay [msec] 0...200msec
Sets the time taken from the original sound to the first early reflection
d
EQ Trim 0...100
Sets the input level of EQ applied to the effect sound
e
Pre LEQ Gain [dB]
Sets the gain of Low EQ
–15.0...+15.0dB
Pre HEQ Gain [dB]
Sets the gain of High EQ
–15.0...+15.0dB
f
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
a
L Delay Time [msec]
Sets the delay time of TapL
0...2730msec
Level
Sets the output level of TapL
0...50
b
C Delay Time [msec]
Sets the delay time of TapC
0...2730msec
Level
Sets the output level of TapC
0...50
c
R Delay Time [msec]
Sets the delay time of TapR
0...2730msec
Level
Sets the output level of TapR
0...50
d
Feedback (C Delay)
Sets the feedback amountof TapC
–100...+100
Src Off...Tempo
Selects the modulation source of the TapC feedback amount
Amt –100...+100
Sets the modulation amount of the TapC feedback amount
Left
Right
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In - Stereo Out
EQ Trim
+
EQ Trim
Pre Delay
Early Reflections
LEQ HEQ
C Delay
R Delay
Left
Right
Feedback
Spread
Wet / Dry
Wet / Dry
Wet: Mono In - Stereo Out / Dry: Stereo In -Stereo Out
Input Level D-mod
High Damp Low Damp
L Delay
Input Level D-mod
+
Level
Level
Level
e
High Damp [%]
Sets the damping amount in the high range
0...100%
☞ Fx:043
Low Damp [%]
Sets the damping amount in the low range
0...100%
☞ Fx:043
f
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level
☞ Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
☞ Fx:037
g
Spread 0...50
Sets the width of the stereo image of the effect sound
☞ Fx:043
h
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
a
Stereo/Cross Stereo, Cross
Switches between stereo delay and cross-feedback delay
b
L Delay Time [msec]
Sets the delay time for the left channel
0.0...1360.0msec
c
R Delay Time [msec]
Sets the delay time for the right channel
0.0...1360.0msec
d
L Feedback
Sets the feedback amount for the left channel
–100...+100
Src Off...Tempo
Selects the modulation source of feedback amount
Amt L –100...+100
Sets the modulation amount of the left channel feedback
e
R Feedback
Sets the feedback amount for the right channel
–100...+100
Amt R –100...+100
Sets the modulation amount of the right channel feedback
f
High Damp [%]
Sets the damping amount in the high range
0...100%
☞ Fx:043
g
Low Damp [%]
Sets the damping amount in the low range
0...100%
☞ Fx:043
h
Input Level Dmod [%] –100...+100
Sets the modulation amount of the input level
☞ Fx:037,
Src
Selects the modulation source for the input level
Off...Tempo
☞ Fx:037
i
Spread –50...+50
Sets the width of the stereo image of the effect sound
☞ Fx:043
j
Wet/Dry Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
Src Off...Tempo
Selects the modulation source of the effect balance
Amt
Sets the modulation amount of the effect balance
–100...+100
Delay
Delay
Stereo/Cross
Left
Right
Feedback
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
Input Level D-mod
Input Level D-mod
High Damp Low Damp
High Damp
Low Damp
Spread
Stereo/Cross
