Appendices
219
The A-mode functions of the REALTIME CONTROLS
are fixed.
Knob1-A: LPF CUTOFF (Filter LPF Cutoff: CC#74)
Control the low pass filter cutoff frequency of the filter.
Simultaneously, CC#74 will be transmitted.
Knob2-A: RESONANCE/HPF (Filter Resonance/HPF Cutoff:
CC#71)
Control the resonance level or the cutoff frequency of the
high pass filter. If the program “Filter Type” is Low Pass
Resonance, the resonance level will be controlled. If “Filter
Type” is Low Pass & High Pass, the cutoff frequency of the
high pass filter will be controlled. Simultaneously, CC#71
will be transmitted.
Knob3-A: EG-Intensity (Filter EG Intensity: CC#79)
Control the filter EG intensity. Simultaneously, CC#79 will
be transmitted.
Knob4-A: EG-Release (Filter, Amplifier EG Release: CC#72)
Control the release time of the filter and amplifier EG.
Simultaneously, CC#72 will be transmitted.
You can assign the function of an assignable switch (sepa-
rately sold Korg PS-1 option) connected to the ASSIGN-
ABLE SWITCH jack.
• This setting is made in Global P2: Controller “Foot
Switch Assign” (2–1a).
If you select a function that includes a CC#, that MIDI
control change message will be transmitted each time
the switch is turned on/off. (Off: 0, On: 127)
Portamento SW (CC#65)
When the “Oscillator Mode” is Single, turning the switch on
will apply portamento regardless of the P2: Edit-Pitch
“Enable” setting, and turning the switch off will not apply
portamento.
If “Oscillator Mode” is Double, and if the P2: Edit-Pitch
“Enable” setting is the same for OSC1 and 2 (i.e., Enable or
Disable for both OSC1 and 2), then portamento will be
applied to OSC1 and 2 when the switch is turned on, and
portamento will not be applied to OSC1 and 2 when the
switch is turned off.
If the P2: Edit-Pitch “Portamento Enable” setting is different
for OSC1 and 2 (i.e., OSC1 is Enable and OSC2 is Disable, or
OSC1 is Disable and OSC2 is Enable), then portamento will
be applied to the OSC whose setting is Enable when the
switch is turned on, and portamento will be applied to nei-
ther OSC when the switch is turned off.
Foot Switch Assign List
Foot Switch Assign
Off The connected foot switch will not function.
Foot SW (CC#82) Alternate Modulation or Effect Dynamic Modulation can be controlled. To control these, set “AMS” or “Dmod Src” to Foot
SW:#82.
Portamento SW (CC#65) Control portamento on/off.
Sostenuto (CC#66) Control the sostenuto effect (which holds only the keys (Note No.) that were being held at the moment that the pedal
switch was turned on).
Soft (CC#67) Turn the soft pedal effect on/off.
Arpeggio SW Turn the arpeggiator on/off. The NRPN message [Bn 63 00 Bn 62 02 Bn 06 00 (off) or 7F (on)] will be transmitted each
time this is turned on/off.
Program Up The switch can be used to select programs or combinations. When in Program P0: Play, the program that follows the cur-
rently selected program will be selected. When in Combination P0: Play, the combination that follows the currently
selected combination will be selected. Simultaneously, a Bank Select message and Program Change message will be
transmitted.
Program Down The switch can be used to select programs or combinations. When in Program P0: Play, the program that precedes the
currently selected program will be selected. When in Combination P0: Play, the combination that precedes the currently
selected combination will be selected. Simultaneously, a Bank Select message and Program Change message will be
transmitted.
Song Start/Stop The switch can be used to start/stop the sequencer. Simultaneously, a MIDI Start or Stop message will be transmitted.
Song Punch In/Out If Sequencer P0: Preference “Recording Setup”(0–7a) is set to Manual Punch In, the switch can be used to punch-in
and punch-out when recording on the sequencer.
Cue Repeat Control This can be used if in Sequencer P1: Cue List, the “Repeat” (1–1d) setting of each step has been set to FS. Turning the
pedal switch on while that step is repeating will be the trigger for advancing to the next step. When the end of the song is
reached, this will advance to the next step (song).
