Korg TRITON proX User Manual

Combination
P0
P1 P2 P3 P4 P7 P8 P9
39
These parameters specify how the arpeggiator will function
within the combination. Two arpeggiators can be running
simultaneously.
This offers a variety of possibilities, such as applying sepa-
rate arpeggio patterns to two sounds that have been
assigned as a keyboard split, or using velocity to switch
between two arpeggio patterns.
7–1: Setup
7–1a: (Arpeggiator Tempo) [040...240, EXT]
☞ “ (Arpeggiator Tempo)” (0–1b).
7–1b: Arpeggiator Assign, Arpeggiator Run A, B
Arpeggiator Assign [Off, A, B]
Assign arpeggiator A or B to each timbre 1–8. When the
front panel ARPEGGIATOR [ON/OFF] key is on, the arpeg-
giator specified for each timbre will operate according to
“Arpeggiator Run A, B” and these settings.
Off: The arpeggiator will not operate.
A: Arpeggiator A will operate. Make settings in the Arpeg-
giator A tab to select the arpeggio pattern and set parame-
ters.
B: Arpeggiator B will operate. Make settings in the Arpeg-
giator B tab to select the arpeggio pattern and set parame-
ters.
If the “Status” (0–1f, 2–1a) of the timbre is INT or BTH,
each timbre 1–8 to which arpeggiator A or B is assigned
will be sounded by the note data generated by the
arpeggiator, regardless of the “MIDI Channel” (2–1a)
setting of the timbre. If a timbre is set to EXT or EX2,
MIDI note data will be transmitted on the “MIDI Chan-
nel” of each timbre.
In this case, arpeggiator A (or B) will be triggered (oper-
ated) by all MIDI channels specified for the “MIDI
Channel” (2–1a) parameter of any timbre 1–8 assigned
to arpeggiator A or B.
If Local Control (“Local Control On,” Global P1: 1–1a) is
ON, the keyboard will not trigger the arpeggiator. The
arpeggiator will be triggered via MIDI IN. Turn Local
Control OFF if you have recorded only the trigger notes
on an external sequencer, and wish to playback the
external sequencer to trigger the TRITON’s arpeggiator.
If you want the note data generated by the arpeggiator
to be recorded on the external sequencer, turn Local
Control ON, and turn off the echo back function on
your external sequencer.
Example 1)
Set the “MIDI Channel” (2–1a) of timbres 1 and 2 to Gch,
and set “Status” (0–1e, 2–1a) to INT. Assign arpeggiator
A to timbre 1 and arpeggiator B to timbre 2, and check
“Arpeggiator Run A, B” (0–3a, 7–1b).
• When the front panel ARPEGGIATOR [ON/OFF] key is
off, timbres 1 and 2 will sound simultaneously (layered)
when you play the keyboard.
• When the front panel ARPEGGIATOR [ON/OFF] key is
turned on, timbre 1 will be played by arpeggiator A,
and timbre 2 will be played by arpeggiator B.
Example 2)
The “MIDI Channel” (2–1a) of timbres 1, 2, 3, 4, and 5 are
set respectively to Gch, Gch, 02, Gch, and 03. Their “Sta-
tus” (0–1e, 2–1a) is set respectively to INT, Off, INT, Off,
and INT. Assign arpeggiator A to timbres 2 and 3, assign
arpeggiator B to timbres 4 and 5, and check “Arpeggiator
Run A, B” (0-3a, 7-1b).
• When the front panel ARPEGGIATOR [ON/OFF] key is
off, playing the keyboard will sound only timbre 1.
(Timbres 2 and 4 are receiving the Gch, but they will not
sound since their “Status” is Off.)
• When you turn on the front panel ARPEGGIATOR
[ON/OFF] key, arpeggiator A will operate for timbres 2
and 3, and arpeggiator B will operate independently for
timbres 4 and 5. (Arpeggiators A and B are triggered by
receiving note data on any MIDI channel of an assigned
timbre, but in this example they are being triggered
from the Gch.)
When you play the keyboard, arpeggiator A will operate
for timbres 2 and 3, but only timbre 3 whose “Status” is
INT will sound. Similarly, arpeggiator B will operate for
timbres 4 and 5, but only timbre 5 whose “Status” is INT
will sound.
In this way, you can make settings so that a timbre does
not sound when the arpeggiator is off, but sounds only
when the arpeggiator is on.
Arpeggiator Run A, B
☞ Link: “Arpeggiator Run A, B” (0–3a).
▼ 7–1: Page Menu Command
Combination P7: Edit-Arp
7–1
7–1a
7–1b
Timbre 1 MIDI Ch=Gch Status=INT
Timbre 2 MIDI Ch=Gch Status=INT
Arpeggiator
A
Arpeggiator
B
Arpeggiator
Assign
A
B
Pattern - A
Pattern - B
Pattern - A
Pattern - B
Trigger
= Gch
Trigger
= Gch
Sounded by normal
keyboard playing
Pattern - B
Pattern - A
Timbre 2 MIDI Ch=Gch Status=Off
Timbre 3 MIDI Ch=2ch Status=INT
Arpeggiator
A
Arpeggiator
B
Arpeggiator
Assign
A
A
Pattern - A
Pattern - B
Trigger
= Gch, Ch2
Trigger
= Gch, Ch3
Timbre 4 MIDI Ch=Gch Status=Off
B
Timbre 5 MIDI Ch=3ch Status=INT
B
Off
Timbre 1 MIDI Ch=Gch Status=INT
Does not sound
Does not sound
0–1A
0–1B
7–1A
