Appendices
217
The following functions can be assigned to the [SW1] or
[SW2] keys.
• For a program, assignments are set by Program P1:
Controller tab “Panel Switch Assign” (1–4a).
• For a combination, assignments are set by Combination
P4: Controller tab “Panel Switch Assign” (4–4a).
• For songs in Sequencer mode, assignments are set by
Sequencer P4: Controller tab “Panel Switch Assign” (4–
7a).
• For Song Play mode, assignments are set by Song Play
P2: Controller Setup “Panel Switch Assign” (2–1a).
• For Sampling mode, assignments are set by Sampling
P4: Controller Setup “Panel Switch Assign” (4–1a).
These settings can be made in Program mode for each
program, in Combination mode for each combination,
and in Sequencer mode for each song. In Song Play
mode and Sampling mode, these settings are made for
the entire mode.
SW1, SW2 Assign List
SW1 Mod.:CC#80 (SW1 Modulation:CC#80)
SW2 Mod.:CC#81 (SW2 Modulation:CC#81)
This effect differs between SW1 and SW2. SW1 is handled as
CC#80, and SW2 is handled as CC#81.
Porta.SW:CC#65 (Portamento Switch:CC#65)
When Program P1: Edit-Basic “Oscillator Mode” (1–1a) is
Single, turning the switch on (LED lit) will apply porta-
mento regardless of the P2: Edit-Pitch “Enable” (2–1c) set-
ting, and turning the switch off will not apply portamento.
If “Oscillator Mode” (1–1a) is Double, and if the P2: Edit-
Pitch “Enable” (2–1c) setting is the same for OSC1 and 2 (i.e.,
Enable or Disable for both OSC1 and 2), then portamento
will be applied to OSC1 and 2 when the switch is turned on
(LED lit), and portamento will not be applied to OSC1 and 2
when the switch is turned off (LED dark). If the P2: Edit-
Pitch “Enable” (2–1c) setting is different for OSC1 and 2 (i.e.,
OSC1 is Enable and OSC2 is Disable, or OSC1 is Disable
and OSC2 is Enable), then portamento will be applied to the
OSC whose setting is Enable when the switch is turned on
(LED lit), and portamento will be applied to neither OSC
when the switch is turned off (LED dark).
JS X Lock, JS+Y Lock, JS-Y Lock, Ribbon Lock,
JS X &Ribbon Lock, JS+Y & Ribbon Lock,
JS-Y & Ribbon Lock, After Touch Lock
The state of the selected controller (joystick, ribbon control-
ler, after touch) will alternate between Lock and Unlock
(Lock when the LED is lit).
While the joystick or after touch is being operated, turning
Lock on will lock (fix) the effect at the current position of
that controller. If Lock is turned on for the ribbon controller,
the effect at that time will be held even after you release
your finger from the ribbon controller. If Lock is off, releas-
ing your finger from the ribbon controller will reset the
effect to the center position.
For example if you select JS (+Y) Lock, move the joystick
away from yourself, and then turn Lock on, the operation
produced by the joystick (+Y) will be locked (held) at that
position. Even if you return the joystick to its original posi-
tion, the modulation will continue to apply. At this time you
can even move the joystick in the –Y direction to apply both
types of modulation (joystick +Y and –Y) simultaneously.
When you Lock the joystick or after touch, MIDI trans-
mission of the corresponding controller will be halted,
but reception will still occur.
SW1/2 Assign
Off no function
SW1 Mod.:CC#80 (SW1 Modulation:CC#80)
SW2 Mod.:CC#81 (SW2 Modulation:CC#81)
Select this when using the switch as an Alternate Modulation or Effect Dynamic Modulation source.
In this case, you must first specify the control destination. Each time the switch is turned On/Off, a
CC#80 (or CC#81) message will be transmitted (Off: 0, On: 127). (
☞P.217)
Porta.SW:CC#65 (Portamento Switch:CC#65) When you press SW1 (or SW2) to turn it on (LED lit), portamento will be applied. Each time this is
turned On/Off, CC#65 will be transmitted (Off: 0, On: 127). (
☞P.217)
Octave Down Each time you press SW1 (or SW2), the pitch will alternate between 1 octave lower and the original
octave setting (1 octave down when the LED is lit).
Octave Up Each time you press SW1 (or SW2), the pitch will alternate between 1 octave higher and the origi-
nal octave setting (1 octave up when the LED is lit).
JS X Lock Lock the effect of the joystick X direction. (
☞P.217)
JS+Y Lock Lock the effect of the joystick +Y direction. (
☞P.217)
JS-Y Lock Lock the effect of the joystick -Y direction. (
☞P.217)
Ribbon Lock Lock the effect of the ribbon controller. (
☞P.217)
JS X & Ribbon Lock Simultaneously lock the effects of the joystick X direction and the ribbon controller. (
☞P.217)
JS+Y & Ribbon Lock Simultaneously lock the effects of the joystick +Y direction and the ribbon controller. (
☞P.217)
JS-Y & Ribbon Lock Simultaneously lock the effects of the joystick -Y direction and the ribbon controller. (
☞P.217)
After Touch Lock Lock the effect of after touch. (
☞P.217)
