124
The EXB* display will depend on the type of option
board.
High Drumsample Select [000...3999: Name]
Select the High Drumsample. The sample selected here will
be sounded by velocities above the “Velocity Sample SW
Lo→Hi” value. (
☞For details on each drum sample, refer to
the separate Voice Name List.)
Category/ROM Drumsample Select menu:
When ROM has been selected for “Bank,” you can press the
popup button to open the “Category/ROM Drumsample
Select” menu. (If a different bank is selected, the usual
popup menu will appear.)
All drum samples will be displayed, grouped into 15 catego-
ries. Use the tabs at left and right to select a category, and the
drum samples in the selected category will be displayed.
It is not possible to edit the category names of drum
samples, or to re-assign the category.
S.Offset (Start Offset)
Checked: The sample waveform will start playback from a
location later than the beginning of the drum sample wave-
form. If the bank is ROM or EXB*, the location of the Start
Offset is pre-determined for each drum sample. This sample
is not valid for drum samples which have no Start Offset.
However when a RAM bank is selected, this will depend on
the selected drum sample. If you select a drum sample that
includes one of the following types of sample, checking this
item will cause playback to start from the Loop Start Address.
• A sample that was recorded (sampled) in Sampling
mode
• A sample whose Loop Start Address was edited in
Sampling mode after the sample was loaded in Disk
mode
• A sample whose Loop Start Address was specified
automatically when it was loaded as an AKAI, AIFF, or
WAVE file in Disk mode
Unchecked: Playback will start from the beginning of the
drum sample waveform.
Rev (Reverse)
Checked: The drum sample waveform will playback in
“one-shot” reverse. If the bank is ROM or EXB*, the location
at which the reverse playback will start and end is pre-deter-
mined for each drum sample.
If the drum sample is already preset for reverse play-
back or reverse loop playback, checking this setting will
not change its playback direction. Such samples are
indicated by in the Drumsample List of the separate
Voice Name List. In the case of a drum sample from the
RAM bank, the sample will play (in reverse) from
“End” (Sampling P2: 2–1c) to “Start.”
This parameter will not change the playback direction
of a sample for which “Reverse” (Sampling P2: 2–1c) is
checked.
Level [–99...+99]
Specify the volume.
Keys for which a value of +99 is specified will sound at a
volume twice as high as the amp level of the program which
uses that drum kit. Keys for which a value of 0 is specified
will sound at the volume of the amp level of the program
which uses that drum kit.
Keys for which a value of –99 is specified will not sound.
Transpose [–64...+63]
Adjust the pitch in semitone steps. +12 is one octave up, and
–12 is one octave down.
Tune [–99...+99]
Adjust the pitch in one-cent steps.
Cutoff (Filter-Cutoff) [–64...+63]
Adjust the cutoff frequency of the filter. The cutoff frequency
for each key is determined by adding this value to the filter
“Frequency (Cutoff Frequency)” (3–1b, 3–5) of the program
that uses this drum kit.
Resonance (Filter-Resonance) [–64...+63]
Adjust the filter resonance. The filter resonance for each key
is determined by adding this value to the filter “Resonance”
(3–1b, 3–5) of the program that uses this drum kit. (When
the “Filter Type” (Program P3: 3–1a) is Low Pass & High
Pass, there will be no resonance effect.)
Attack (Amp-Attack) [–64...+63]
Adjust the attack time of the volume (Amplifier). The attack
time for each key is determined by adding this value to the
amp EG Attack Time of the program that uses this drum kit.
Decay (Amp-Decay) [–64...+63]
Adjust the decay time of the volume (Amplifier). The decay
time for each key is determined by adding this value to the
amp EG Decay Time of the program that uses this drum kit.
5–1c: Low Drumsample
Bank [ROM, RAM, EXB*, EXB*]
Specify the bank of the Low Drumsample (☞“Bank” 5–1b).
Low Drumsample Select [0000...3999: Name]
Select the Low Drumsample. This will be sounded by veloc-
ities lower than the value set for “Velocity Sample SW
Lo→Hi” (5–1a). (
☞For details on each drum sample, refer to
the separate Voice Name List.)
Select drumsamples from the Category/Drumsample Select
menu (
☞“High Drumsample Select” 5–1b).
S.Offset (Start Offset)
Rev (Reverse)
Level [–99...+99]
Transpose [–64...+63]
Tune [–99...+99]
Cutoff (Filter-Cutoff) [–64...+63]
Resonance (Filter-Resonance) [–64...+63]
Attack (Amp-Attack) [–64...+63]
Decay (Amp-Decay) [–64...+63]
☞ “5–1b: High Drumsample.”
