L3 Mobile-Vision Flashback3 - DVR Specifications

DVR Specifications
Flashback3 & Flashback HD User’s Guide
Page 250 L3 Mobile-Vision  6.23.2017
DVR Specifications
Flashback Technical Specifications
Recorder Type Digital, mobile application specific.
Recording Media Secure Digital (SD) card with maximum 128 gigabyte
storage capability.
Compression System supports video compression using the MPEG
4 part 10 standard at up to 2.5 megabits per second for
the first video stream and up to 1.5 megabits per
second for the second stream.
Video Inputs  Camera 1: 2 – 30 frames-per-second
 Camera 2: 2 – 30 frames-per-second
 Camera(s) 3 – 5: Same frames-per-second
as
C
amera 2
Audio Inputs  VLP1
 VLP2 (optional)
 Wired Mic (Optional – backseat); mic level input
External Inputs +5vdc – +15vdc:
 Emergency Lights
 Siren
 Brakes
 Ignition
 Auxiliary 1
 Auxiliary 2
AV Outputs  NTSC Video
 Line Level Audio
Data Communication  Wireless 802.11(a) (b) (g) (a/n) (g/n)
 RS232C
 10/100/1000 Ethernet
 USB 2.0 Interface
Record Trigger Types  Manual. Record triggered by the user via the
R
ecord buttons or VLP2/VLX mic
 Event. Record triggered automatically by activating
the emergency lights, siren, or auxiliary inputs, or
by exceeding the GPS speed threshold
Recording Modes  Regular Record. A recording initiated by one of
the Record Trigger Types described above.
 Background Record. A continuous recording that
occurs in the background at a low frame rate. Only
occurs when Regular Record is not in process.
Resolution 320x240 to 720x480 (Flashback3)
320x240 to 1280x720 (FlashbackHD)
