4-60 Finisher Service Manual
4024-XXX
8. Remove the screw securing the eject clamp lever assembly (C) from the shaft (D) on the rear of the
finisher.
9. Remove the eject clamp lever assembly (C).
10. Remove the e-clip securing the shaft (D) to the rear of the finisher.
11. Remove the 8 mm bushing (E) on the rear side.
Rear
C
Screw
E-clip
E
D
