Lexmark X925 - Page 393

Locations 5-5
7541-03x
RIP board
Connector Pin no. Signal
J3 - ICC board 1 GND
2 FB_LAMP_ON_R
3 +24V
4 +24V
5 GND
6 5V_FB_CDU
7 +5V_SCANNER
8 FB_PWRSVR_R
9 FBR_AFE_SH_R
10 FBR_AFE_SEN_R
11 FBR_AFE_SCK_R
12 FBR_AFE_SDIO_R
13 GND
14 FBR_AFE_NRST_R
15 GND
16 FB_LVDS_RXIN0-
17 FB_LVDS_RXIN0+
18 GND
19 FB_LVDS_RXIN1-
20 FB_LVDS_RXIN1+
21 GND
22 FB_LVDS_RXIN2-
23 FB_LVDS_RXIN2+
24 GND
25 FB_LVDS_RXCLK-
26 FB_LVDS_RXCLK+
27 GND
28 FB_LVDS_MCLK-
29 FB_LVDS_MCLK+
30 GND
