5-6 Service Manual

7541-03x

J4 1 GND

4 +24V_FEED_FAN

5 GND

6 TOP_FB_CN

7 BOOT_SEL_CN

8 +5V SCANNER

9 +5V SCANNER

10 GND

11 MDC_TXD_CN

12 MDC_RXD_CN

13 GND

14 ADF_PAPER_PRES_R

15 FB_COVER_CLOSING_R

16 GND

17 FB_NHOME_R

18 ADF_INTERVAL_R

19 GND

20 MDC_RST_NR

21 +3.3V

22 GND

23 NC_MDC_23

24 IC2_CLK

25 IC2_DATA

26 GND

RIP board

Connector Pin no. Signal
