Locations 5-15

7541-03x

CN6 Fuser entry sensor 1 GND

2 FUIN_SW

3 LDPRG

CN7 Paper exit, 1 GND

2 PEX_SW

3 IDPRG

Bin full sensors 4 GND

5STACK_SW

6+5V

CN8 Theta sensor 1 A

2THETA

3GND

CN9 N.C

CN 10

CN11 HVPS 1 VCC24VFAN

2GND

3 HV24V_2

4HINB

5DACLK

6 DASO

7DARIN

8 DA_LAT

CN12 N.C

CN13 OPTION 1 ADR0

2 ADR1

3 OPTION_RST

4 OPTION_RXD

5OPTION_TXD

6 OPT_24V

7 OPT_24V

8GND

9GND

10 OPT_5V

11 GND

Printhead controller board

Connector Connects to Pin no. Signal
