5-16 Service Manual

7541-03x

CN14 Density sensor 1 GLED

2VMON

3GND

4+5V

5VOUT

CN15 LVPS 1 +5V_IN

2+5V_GND

3 +24V_IN

4 +24V_GND

Engine board 5 +24VSW

CN16 LVPS 1 +24V_GND

2 HV25V

3 SLEEP1

4 SLEEP2

5HT1

6HT2

7HT3

8 ZEROCRS

CN17 Toner sensor K 1 TNSETK

2k-k

3GND

4 TSZANK

5+5V

Toner sensor C 6 TNSETC

7k-k

8GND

9 TSZANC

10 +5V

CN18 Toner sensor Y 1 TNSETY

2k-k

3GND

4 TSZANY

5+5V

Toner sensor M 6 TNSETM

7k-k

8GND

9 TSZANM

10 +5V

Printhead controller board

Connector Connects to Pin no. Signal
