Lexmark X925 - Page 409

To Next Page

To Previous Page

Locations 5-21

7541-03x

CN8 Paperfeed clutches Paperfeed clutches 1 VCC24V

2/PF1CL

3 VCC24V

4 /TRCL

5 VCC24V

6/MLTCL

CN9 Waste toner 1 GND

2HTONER

3/LD

Belt pos sensor 4 GND

5 BELT U/D

6/LD

CN10 Duplex solenoid DUPSOL

GND

CN12 Full sensor 1 GND

2PFLIFTSW

3LD

PE Sensor STD tray 4 GND

5 PP EMP

6LD

PE Sensor MPF tray 7 GND

8MPF DET

9LD

Reg sensor 10 GND

11 PRGSW

12 PRGSW5V

CN13 Duplex clutch 1 DUPOUTCL

3GND

CN14 Exit sensor 1 GND

2 DUP INSW

3+5V

CN15 Belt motor 1 1A BELT

2 1B BELT

3 2A BELT

4 2B BELT

Engine board

Connector Connects to Pin no. Signal
