5-22 Service Manual
7541-03x
CN16 Paperfeed motor /
Fuser motor
Paperfeed motor 1A FEED
1B FEED
2A FEED
2B FEED
Fuser / paper exit motor 1A FUSER
1B FUSER
2A FUSER
2B FUSER
CN17 Motor Y Motor 1 DSYMOY -A
2 DSYMOY -B
3 DSYMOY -A
4 DSYMOY -B
CN18 Motor M Motor 1 DSMMOY -A
2 DSMMOY -B
3 DSMMOY -A
4 DSMMOY -B
CN19 Motor C Motor 1 DSCMOY -A
2 DSCMOY -B
3 DSCMOY -A
4 DSCMOY -B
CN20 Motor K Motor 1 DSKMOY -A
2 DSKMOY -B
3 DSKMOY -A
4 DSKMOY -B
CN21 Fuser fan 1 FFAN
2FFALM
3GND
CN22 Main fan 1 CFAN
2CFALM
3GND
CN23 Main switch 1 +24V PR
2 +24V PR
CN24 LVPS 1 +5V IN
2+5V GND
3 +24V PR
4+24V GND
5+24 V
Engine board
Connector Connects to Pin no. Signal
