LSIS sv-ip5a User Manual

Chapter 6 - Parameter Description [FU1]
6-18
FU1-51~52: Energy Save, Energy Save Level
This function is used to reduce the output voltage in
applications that do not require high torque and
current at its steady speed. The inverter reduces its
output voltage after accelerating to the reference
frequency (steady speed) if the energy save level is
set at 20%. This function may cause over-current trip
due to the lack of output torque in a fluctuating load.
When Energy Save is ON, it may take longer during
deceleration to stop.
FU1-51 setting Description
0 None Disabled (Factory setting)
1 Manual
Energy save ON by decreasing
the output with the value set in
FU1-52.
2 Auto Energy save ON automatically.
Code LCD Name Default Range
FU1-52
Manual
Save %
Energy
save %
0
[%]
0~30
[%]
FU1-54: Integrating Wattmeter
 Displays both MWh and kWh in FU1-54.
Ex) 1500 kWh
 Max Cumulative value is displayed in FU1-54
as shown below.
Ex) 9,999,999.9kWh
 Press [PROG] key for 5 sec to reset the value
stored in FU1-54.
☞ Caution: FU1-54 value may differ from the
actual value due to the margin.
☞ Caution: Only KWh appears on 7-Segment
Keypad.
FU1-55: Inverter temperature
IGBT’s surface temperature is displayed in FU1-55.
FU1-56: Motor temperature
Motor temperature detected by external thermal
sensor terminal (NT) is displayed in FU1-56.
FU1 ► Manual save%
52 0 %
0 52
Factory Default: 0 % 0
FU1 ► Energy save
51 None
0 51
Factory Default: 0 0
FU1▶KiloWattHour
54 1M 00.0kWh
FU1▶KiloWattHour
54 9999M999.9kWh
FU1 ► Inv. Temp
55 44
44 55
Factory Default: 44 44
FU1 ► Motor Temp
56 0
0 56
Factory Default: 0 0
