Chapter 2 - Specification
2-2
2.3 380 ~ 480V Class (37~90kW / 50~125HP)
Model Number
(SVxxxiP5A-4)
370 450 550 750 900
Capacity [kVA]
(1)
59.8 72.5 87.6 121.1 145.8
HP
50 60 75 100 125
motor
rating
(2)
kW
37 45 55 75 90
75 91 110 152 183
Fan or
pump
load
Current [A]
(110% overload)
110% 1 Minute (Normal Duty)
HP
40 50 60 75 100
motor
rating
(2)
kW
30 37 45 55 75
General
load
Current [A]
(150% overload)
150% 1 Minute (Heavy Duty)
Frequency 0.01 ~ 120 Hz
Output
ratings
Voltage 380 ~ 480 V
(3)
Voltage 3φ 380 ~ 480 V (-15% ~ +10 %)
Input
ratings
Frequency 50/60 Hz (± 5 %)
Protection degree IP00 / UL Open
(3)
Standard Type 27(59.5) 27(59.5) 29 (64) 42 (92.6) 43 (94.8)
Weight [kg (lbs.)]
Bulit-in DCL Type 39(86) 40(88.2) 42(92.6) 67(147.4) 68(149.9)
2.4 380 ~ 480V Class (110~450kW / 150~600HP)
Model Number
(SVxxxiP5A-4)
1100 1320 1600 2200 2800 3150 3750 4500
Capacity [kVA]
(1)
178 210 259 344 436 488 582 699
HP
150 200 250 300 350 400 500 600
motor
rating
(2)
kW
110 132 160 220 280 315 375 450
223 264 325 432 547 613 731 877
Fan or
pump
load
Current [A]
(110% overload)
110% 1 Minute (Normal Duty)
HP
125 150 200 250 300 350 400 500
motor
rating
(2)
kW
90 110 132 160 220 280 315 375
183 223 264 325 432 547 613 731
General
load
Current [A]
(150% overload)
150% 1 Minute (Heavy Duty)
Frequency 0.01 ~ 120 Hz
Output
ratings
Voltage 380 ~ 480 V
(3)
Voltage 3φ 380 ~ 480 V (-15% ~ +10 %)
Input
ratings
Frequency 50/60 Hz (± 5 %)
Protection degree IP00 / UL Open
(4)
DCL (DC Choke) Built-in External Option
Weight [kg (lbs.)]
101
(222.7)
101
(222.7)
114
(251.3)
200
(441.9)
200
(441.9)
243
(535.7)
380
(837.7)
380
(837.7)
