2. AC Input Fuse and AC / DC Reactor
AC Reactor DC Reactor
Voltage
Mortor
[kW]
Inverter
Model
AC Input Fuse
[A]
[mH] [A] [mH] [A]
5.5 SV055iP5A-2 40 0.39 30 1.37 29
7.5 SV075iP5A-2 60 0.28 40 1.05 38
11 SV110iP5A-2 80 0.20 59 0.74 56
15 SV150iP5A-2 100 0.15 75 0.57 71
18.5 SV185iP5A-2 125 0.12 96 0.49 91
22 SV220iP5A-2 150 0.10 112 0.42 107
200V
Class
30 SV300iP5A-2 200 0.07 160 0.34 152
5.5 SV055iP5A-4 20 1.22 15 5.34 14
7.5 SV075iP5A-4 30 1.14 20 4.04 19
11 SV110iP5A-4 40 0.81 30 2.76 29
15 SV150iP5A-4 60 0.61 38 2.18 36
18.5 SV185iP5A-4 70 0.45 50 1.79 48
22 SV220iP5A-4 80 0.39 58 1.54 55
30 SV300IP5A-4 100 0.287 80 1.191 76
37 SV370iP5A-4 125 0.232 98 0.975 93
45 SV450iP5A-4 150 0.195 118 0.886 112
55 SV550iP5A-4 175 0.157 142 0.753 135
75 SV750iP5A-4 250 0.122 196 0.436 187
90 SV900iP5A-4 300 0.096 237 0.352 225
110 SV1100iP5A-4 350 0.081
289
Built-in
132 SV1300iP5A-4 400 0.069
341 Built-in
160 SV1600iP5A-4 450 0.057
420 Built-in
220 SV2200iP5A-4 700 0.042
558 Built-in
280 SV2800iP5A-4 800 0.029
799 Built-in
315 SV3150iP5A-4 900 0.029
799
0.090 836
375 SV3750iP5A-4 1000 0.024
952
0.076 996
400V
Class
450 SV4500iP5A-4 1200 0.024
952
0.064 1195
