LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-2
5.2 Parameter list
[DRV Group]
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
DRV-00
(1)
9100
Command Frequency
(Output Frequency during
motor run, Reference
Frequency during motor
stop), Output Current (LCD)
Cmd. freq 0 to FU1-30[Hz] 0 [Hz] O 6-1
5.5~90kW
(7.5~125HP)
20 [sec]
DRV-01 9101
Acceleration
Time
110~450kW
(150~600HP)
Acc. Time 0 to 6000 [sec]
60 [sec]
O 6-3
5.5~90kW
(7.5~125HP)
30 [sec]
DRV-02 9102
Deceleration
Time
110~450kW
(150~600HP)
Dec. time 0 to 6000 [sec]
90 [sec]
O 6-3
DRV-03 9103
Drive Mode
(Run/Stop Method)
Drive mode
0 (Keypad)
1 (Fx/Rx-1)
2 (Fx/Rx-2)
3 (Int. 485)
1
(Fx/Rx-1)
X 6-4
DRV-04 9104
Frequency Mode (Frequency
setting method)
Freq mode
0 (Keypad-1)
1 (Keypad-2)
2 (V1)
3 (V1S)
4 (I)
5 (V1+I)
6 (Pulse)
7 (Int. 485)
8 (Ext. PID)
0
(Keypad-1)
X 6-4
DRV-05 9105 Step Frequency 1 Step freq-1 10 [Hz] O
DRV-06 9106 Step Frequency 2 Step freq-2 20 [Hz] O
DRV-07 9107 Step Frequency 3 Step freq-3
0 to FU1-30[Hz]
30 [Hz] O
6-5
DRV-08 9108 Output Current Current * [A] * [A] * 6-5
DRV-09 9109 Motor Speed Speed * [rpm] * [rpm] * 6-5
DRV-10 910A DC link Voltage DC link Vtg * [V] * [V] * 6-6
DRV-11 910B User Display Selection User disp
Output
voltage [V]
* 6-6
DRV-12 910C Current Trip Display Fault * * * 6-6
DRV-13 910D Motor Direction
Use Only
7-Segment Keypad
0 (Forward)
/ 1 (reverse)
0 O
6-7
DRV-14
(2)
910E
Target/Output
Frequency Display
Tar. Out. Freq. * [Hz] * [Hz] *
6-7
DRV-15
(2)
910F
Reference/Feedback
Frequency Display
Ref. Fbk. Freq. * [Hz] * [Hz] * 6-7
DRV-16 9110 Speed Unit Selection Hz/Rpm Disp Hz or Rpm Hz O 6-8
DRV-18
(2)
9112 PID Parameter PidParameter * [Hz] * [Hz] X 6-8
DRV-19 9113 AD Parameter AD Parameter AD AD X 6-8
DRV-20
(3)
9114 EXT-PID Parameter Ext Pid Para % % X 6-9
DRV-91
(4)
915B Drive mode 2 Drive mode2
0 (Keypad)
1 (Fx/Rx-1)
2 (Fx//Rx-2)
1
(Fx/Rx-1)
X 6-42
DRV-92 915C Frequency mode 2 Freq mode2
0 (Keypad-1)
1 (Keypad-2)
2 (V1)
3 (V1S)
4 (I)
5 (V1+I)
6 (Pulse)
0
(Keypad-1)
X 6-42
