LSIS sv-ip5a User Manual

Chapter 6 - Parameter Description [I/O]
6-39
I/O-11~16: Frequency command setting via pulse
(A0/B0)
□
□
□
Set the frequency command from control terminal A0
or B0. It is settable when DRV-04 [Frequency mode]
is set to “Pulse”.
User-selected Unit appears in [**]. To change the
unit, more than one in APP-02 [PID operation
selection] and APP-80 [Ext. PID operation selection]
is set to “Yes” and then select the desired unit
Percent, Bar, mBar, kPa, and Pa among in I/O-88
[Pulse Input user unit selection].
Code Factory setting Setting range
I/O-11 (A) (A), (A)+(B)
I/O-12 10 [msec] 0 ~ 9999 [msec]
I/O-13 0 [KHz] 0 ~ 10 [KHz]
0 [Hz] 0 ~ Max frequencyI/O-14
0 [**] 0 ~ 100.00[**]
I/O-15 10 [KHz] 10 ~ 100 [KHz]
60 [Hz] 0 ~ Max frequency
I/O-16
0 [**] 0 ~ 100.00[**]
Note: Do not apply pulse to both A0, B0 terminals
when I/O-12 set value is A.
Pulse information
T/N Default Setting range
High: +3~+12V Max
Low: +2.5V Max
A0 A Pulse Input
Max Input Freq.: 100KHz
High: +3~+12V Max
Low: +2.5V Max
B0 B Pulse Input
Max Input Freq.: 100KHz
Note: Use Open Collector type encoder for Pulse
input with Max. 12 V Power supply.
Code
LCD
Display
Description
I/O-11 P Pulse Set
Set one of the frequency setting
input method either A or A+B.
I/O-12 P filter
Set the embedded filter constant
for P Pulse input.
I/O-13 P Pulse x1
Set the Minimum frequency for P
Pulse input.
P freq y1
Set the output frequency
corresponding to P Pulse input
minimum frequency (I/O-13).
I/O-14
P [**] y1
Set the target value corresponding
to P Pulse input minimum
frequency (I/O-13)
I/O-15 P Pulse x2
Set the Maximum frequency for P
Pulse input.
P freq y2
Set the output frequency
corresponding to P Pulse input
Maximum frequency (I/O-15).
I/O-16
P [**] y2
Set the target value corresponding
to P Pulse input maximum
frequency (I/O-15)
Note: Increase filter time constant when the noise
interference deteriorates stable operation. Increasing
that makes response time slower.
Note: When setting P Pulse Input Min/Max Freq. via
motor encoder, set the value for encoder pulse as the
following;
I/O► P pulse set
11 (A)
1 11
Factory Default: (A) 1
I/O► P filter
12 10 msec
10 12
Factory Default: 10 msec 10
I/O► P pulse x2
15 10.00 KHz
10 15
Factory Default: 10.0 KHz 10.0
I/O► P pulse y2
16 60.00 Hz
60.00 16
Factory Default: 60.00 Hz 60.00
