Chapter 8 - Options
8-12
8.2.6 NEMA TYPE 1 Optional Conduit Box
1) NEMA TYPE 1 Enclosure for conduit connection
■ General
NEMA TYPE 1 Conduit Box: This kit enables an inverter to be installed on the wall without the inverter
panel and meets NEMA Type 1. It should be installed to meet NEMA 1 for 15~90kW UL Open Type
inverters. However, installing this option does not mean UL Type 1. Please purchase Standard UL Type 1
models if needed.
■ Installation:
Remove the metal plate on the bottom with the driver and install this kit on to the same place by the
screws from the metal plate.
[Conduit box for 150~185iP5A]
[Conduit box for 220~300iP5A]
To Next Page
