Chapter 5 ā Parameter list
5-7
[FU2 GROUP]
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
FU2-00 9300 Jump to desired code # Jump code
1 to 95
(Use Only LCD
Keypad)
40 O 6-24
FU2-01 9301 Last trip 1 Last trip-1
0 (None)
* 6-24
FU2-02 9302 Last trip 2 Last trip-2 0 (None) * 6-24
FU2-03 9303 Last trip 3 Last trip-3 0 (None) * 6-24
FU2-04 9304 Last trip 4 Last trip-4 0 (None) * 6-24
FU2-05 9305 Last trip 5 Last trip-5
By pressing [PROG]
and [ā²] key, the
frequency, current,
and operational status
at the time of fault can
be seen.
0 (None) * 6-24
0(No)
FU2-06 9306 Erase trips Erase trips
1(Yes)
0 (No) O 6-24
FU2-07 9307 Dwell Frequency Dwell time 0 to 10 [sec] 0 [sec] X 6-24
FU2-08
(12)
9308 Dwell Frequency Dwell freq FU1-32 to FU1-30 5 [Hz] X 6-24
0(No)
FU2-10 930A Frequency Jump Selection Jump freq
1(Yes)
0 (No) X 6-25
FU2-11
(13)
930B
Jump Frequency 1 Low
jump lo 1
0 to FU2-12
10 [Hz] O
FU2-12 930C
Jump Frequency 1 High
jump Hi 1
FU2-11 to FU1-30
15 [Hz] O
FU2-13 930D
Jump Frequency 2 Low
jump lo 2
0 to FU2-14
20 [Hz] O
FU2-14 930E
Jump Frequency 2 High
jump Hi 2
FU2-13 to FU1-30
25 [Hz] O
FU2-15 930F
Jump Frequency 3 Low
jump lo 3
0 to FU2-16
30 [Hz] O
FU2-16 9310
Jump Frequency 3 High
jump Hi 3
FU2-15 to FU1-30
35 [Hz] O
6-25
0(No)
FU2-20 9314 Power ON Start Selection Power-on run
1(Yes)
0 (No) O
0(No)
FU2-21 9315 Restart after Fault Reset RST restart
1(Yes)
0 (No) O
FU2-22 9316 Speed Search Selection Speed Search
0000 to 1111
(Bit Set)
0000 X
6-25
FU2-23
(14)
9317
P Gain During Speed Search
SS P-gain 0 to 9999 200 O 6-27
FU2-24 9318
I Gain During speed search
SS I-gain 0 to 9999 500 O 6-27
FU2-25 9319
Number of Auto Retry
Retry number 0 to 10 0 O 6-28
FU2-26
(15)
931A
Delay Time
Before Auto Retry
Retry delay 0 to 60 [sec] 1 [sec] O 6-28
To Next Page
