Chapter 5 – Parameter list
5-6
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
0 (0.01 sec)
1 (0.1 sec)
FU1-74 924A Accel/Decel Time Scale Time scale
2 (1 sec)
1 (0.1 sec) O 6-23
FU1-90
(31)
925A Safety STOP Inertia Rate STOP Inertia 1 to 9999 10 X
6-23
* The gray-highlighted codes are hidden parameters and will appear when the related functions are to be set.
(5) Only displayed when FU1-02, FU1-03 is set to [S-Curve].
(6) Only displayed when FU1-20 is set to [DC-start].
(7) Only displayed when FU1-23 is set to [DC-break].
(8) Only displayed when FU1-33 is set to [Yes].
(9) FU1-41~48 Only displayed when FU1-40 is set to [User V/F].
(10) Only displayed when FU1-51 is set to [Manual].
(11) Only displayed when FU1-66 is set to [Yes].
(31) Only displayed when FUN-28 is set to [Yes].
