Chapter 4 - Operation
4-4
4.1.3 Parameter groups
The iP5A series inverter has 5 parameter groups separated according to their applications as indicated in the
following table.
The iP5A series inverter provides two kinds of keypad. One is 32-character alphanumeric LCD keypad and the
other is 7-Segment LED keypad.
Parameter
Group
LCD Keypad
Description
Drive Group DRV
Command Frequency, Accel/Decel Time etc.
Basic function Parameters
Function 1 Group FU1
Max. Frequency, Amount of Torque Boost etc.
Parameters related to basic functions
Function 2 Group FU2
Frequency Jumps, Max/Min Frequency Limit etc.
Basic Application Parameters
Input / Output
Group
I/O
Programmable Digital Input/Output Terminal
Setting, Auto Operation etc. Parameters needed for
Sequence Operation
Application
Group
APP
PID, MMC (Multi-Motor Control), 2
nd
motor
operation etc. Parameters related to Application
function
Refer to the function descriptions for detailed description of each group.
