LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-19
[EXT GROUP]
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
EXT-00 9500 Jump Code
Jump code
1 to 45 1 O
EXT-01 9501 Type of SUB Board
Sub B/D
Sub-E * *
EXT-40 9528
Current Output
Termianl 1(CO1) Selection
AM1 mode
Frequency
Current
Voltage
DC link Vtg
Ext PID Out
Frequency
O
EXT-41 9529
Adjust Gain of Current
Output Termianl 1(CO1)
AM1 adjust
10 – 200 [%] 100 [%] O
EXT-42 952A
Adjust Offset of Current
Output Termianl 1(CO1)
AM1 Offset
0 – 100 [%] 0 [%] O
EXT-43 952B
Current Output
Termianl 2(CO2) Selection
AM2 mode
Frequency
Current
Voltage
DC link Vtg
Ext PID Out
DC link Vtg O
EXT-44 952C
Adjust Gain of Current
Output Termianl 2(CO2)
AM2 adjust
10 – 200 [%] 100 [%] O
EXT-45 952D
Adjust Offset of Current
Output Termianl 2(CO2)
AM2 Offest
0 – 100 [%] 0 [%] O
Refer to
the
correspo-
nding
option
manual
* Only the above EXT group displayed when the corresponding option board is installed.
* Refer to the SUB board option manual for details.
