LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-10
[I/O GROUP]
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
I/O-00
9400
Jump to desired code # Jump code
1 to 98
(LCD Keypad Only)
1 O 6-37
I/O-01
(17)
9401
Filtering Time Constant for
V1 Signal Input
V1 filter 0 to 9999 [msec] 10 [msec] O
I/O-02
9402
V1 Input Minimum Voltage
V1 volt x1 0 to 12[V] 0 [V] O
0 to FU1-30 [Hz]
I/O-03
9403
Frequency Corresponding to
V1 Input Minimum Voltage
V1 freq y1
0 to 100.00 [**](18)
0 [Hz] O
I/O-04
9404
V1 Input Minimum Voltage
V1 volt x2 0 to 12[V] 10 [V] O
0 to FU1-30 [Hz]
I/O-05
9405
V1 Input Maximum Voltage V1 freq y2
0 to 100.00 [**] (18)
60 [Hz] O
6-37
I/O-06
9406
Filtering Time Constant for I
Signal Input
I filter 0 to 9999 [msec] 10 [msec] O
I/O-07
9407
I Input Minimum Current
I curr x1 0 to 20 [mA] 4 [mA] O
0 to FU1-30 [Hz]
I/O-08
9408
Frequency Corresponding to
I Input Minimum Current
I freq y1
0 to 100.00 [**](18)
0 [Hz] O
I/O-09
9409
Filtering Time Constant for I
Signal Input
I curr x2 0 to 20 [mA] 20 [mA] O
0 to FU1-30 [Hz]
I/O-10
940A
Frequency Corresponding to
I Input Maximum Current
I freq y2
0 to 100.00 [**](18)
60 [Hz] O
6-38
0 (A+B)
I/O-11
940B
Pulse input method P pulse set
1 (A)
1 (A) O
I/O-12
940C
Pulse input filter P filter 0 to 9999 [msec] 10 [msec] O
I/O-13
940D
Pulse input Minimum
frequency
P pulse x1 0 to 10 [kHz] 0 [kHz] O
0 to FU1-30 [Hz]
I/O-14
940E
Frequency corresponding to
I/O-13 Pulse input Maximum
frequency
P freq y1
0 to 100.00 [**](18)
0 [Hz] O
I/O-15
940F
Frequency corresponding to
I/O-15
P pulse x2 0 to 100 [kHz] 10 [kHz] O
0 to FU1-30 [Hz]
I/O-16
9410
Pulse input Minimum
frequency
P freq y2
0 to 100.00 [**](18)
60 [Hz] O
6-39
0 (None)
1 (half of x1)
I/O-17
9411
Criteria for Analog Input
Signal Loss
Wire broken
2 (below x1)
0 (None) O
0 (None)
1 (FreeRun)
I/O-18
9412
Operating selection at Loss
of Freq. Reference
Lost command
2 (Stop)
0 (None) O
I/O-19
9413
Waiting Time after Loss of
Freq. Reference
Time out 0.1 to 120 [sec] 1.0 [sec] O
