Chapter 3 - Installation
3-7
6) Power Terminals:
(1) 5.5 ~ 30 kW (200V/400V Class)
R(L1) S(L2) T(L3) G P1(+) P2(+) N(-) U V W
(2) 37~90kW (50~125HP) / 315~450kW (400~600HP) <400V Class>
R(L1) S(L2) T(L3) P1(+) P2(+) N(-) U V W
(3) 15~18.5kW (20~25HP) <Built-in DC Reactor Type, 400V Class>
R(L1) S(L2) T(L3) P(+) N(-) U V W
(4) 22~30kW (30~40HP) <Built-in DC Reactor Type, 400V Class>
R(L1) S(L2) T(L3) P(+) N(-) U V W
(5) 37~90kW (50~125HP) / 110 ~280kW (150~350HP) <Built-in DC Reactor Type, 400V Class>
R(L1) S(L2) T(L3) P2(+) N(-) U V W
ā Note : P1(+) is not provided for wiring.
Symbol Description
R(L1), S(L2), T(L3) AC Line Voltage Input
G Earth Ground
P1(+), P2(+) External DC Reactor (P1(+)-P2(+)) Connection Terminals
(Jumper must be removed).
P2(+) ,N(-) or
P(+), N(-)
DB Unit (P2(+)-N(-)) Connection Terminals
U, V, W 3 Phase Power Output Terminals to Motor
