LSIS sv-ip5a User Manual

Chapter 8 - Options
8-3
8.2.2 Remote cable
Ordering No.
Description
051050025 Remote cable – 2m
051050026 Remote cable – 3m
051050027 Remote cable – 5m
8.2.3 DB (Dynamic Braking) Unit
Refer to DB Unit option manual for details.
1) DBU Models
UL Inverter Applicable motor rating DB Unit Dimension
11 ~ 15 kW (15 ~ 20 HP) SV150DBU-2
18.5 ~ 22 Kw (25 ~ 30 HP) SV220DBU-2
Group 1.
See 4) Dimensions
30 ~ 37 kW (40 ~ 50 HP) SV037DBH-2
200V class
45 ~ 55 kW (60 ~ 75 HP) SV037DBH-2, 2Set
Group 2.
See 4) Dimensions
11 ~ 15 kW (15 ~ 20 HP) SV150DBU-4
18.5 ~ 22 kW (25 ~ 30 HP) SV220DBU-4
Group 1.
See 4) Dimensions
30 ~ 37 kW (40 ~ 50 HP) SV037DBH-4
45 ~ 55 kW (60 ~ 75 HP)
Non UL
type
400V class
75 kW (100 HP)
SV075DBH-4
Group 2.
See 4) Dimensions
11 ~ 15 kW (15 ~ 20 HP) SV150DBU-2U
18.5 ~ 22 kW (25 ~ 30 HP) SV220DBU-2 U
30 ~ 37 kW (40 ~ 50 HP) SV370DBU-2 U
200V class
45 ~ 55 kW (60 ~ 75 HP) SV550DBU-2 U
11 ~ 15 kW (15 ~ 20 HP) SV150DBU-4 U
18.5 ~ 22 kW (25 ~ 30 HP) SV220DBU-4 U
30 ~ 37 kW (40 ~ 50 HP) SV370DBU-4 U
45 ~ 55 kW (60 ~ 75 HP) SV550DBU-4 U
75 kW (100 HP) SV750DBU-4 U
90~110 kW (125 ~ 150 HP) SV550DBU-4, 2Set
132~160 kW (200 ~ 250 HP) SV750DBU-4, 2Set
220 kW (300 HP) SV750DBU-4, 3Set
Group 3.
See 4) Dimensions
280~315 kW (350 ~ 400 HP) -
UL Type
400V class
375~450 kW (500 ~ 600 HP) -
2) Terminal Configuration
- Group 1:
- Group 2:
- Group 3:
Terminals Description Terminals Description
G Ground terminal N Connect to inverter terminal N
B2 Connect to DB Resistor’s B2 P Connect to inverter terminal P1
B1 Connect to DB Resistor’s B1 CM OH Common
N Connect to inverter terminal N
P Connect to inverter terminal P1
OH*
Over Heat Trip output terminal
(Open Collector output: 20mA, 27V DC)
N B2 P/B1G
B2B1N P G
B2 B1 N P
OH
G
CM
