Chapter 4 - Operation
4-6
4.2 Operating Example
4.2.1 Easy Start Operation
Easy Start Operation is activated by pressing STOP key on the Keypad for 2~3 seconds and inverter begins
operation via Keypad (FWD/REV RUN/STOP). Drive mode is preset to V/F and reference frequency to
JOG.
4.2.2 Operation via Control terminal + Keypad
Setting: DRV-03 [Drive Mode (Run/Stop method)] = Fx/Rx-1
DRV-04 [Frequency Mode (Freq. setting method)] = Keypad
With above setting, Freq setting via terminal & Run/Stop via Keypad disabled
1) Check the LCD display when Power ON. Otherwise, change the setting correctly as shown above.
2) Turn the FX (or RX) terminal ON. Then FWD (or REV) LED will be lit.
3) When setting the Ref. Freq to 60 Hz using PROG/ENT/SHIFT, ▲ keys, the motor will rotate at 60Hz.
FWD (or REV) LED will be flickering during Acceleration/ Deceleration.
4) Turn the FX (or RX) terminal Off. Then Stop LED will be lit.
DRV▶T/K 0.0 A
00 STP 0.00Hz
DRV▶T/K 0.0 A
00 FWD 0.00Hz
DRV▶T/K 0.0 A
00 STP 60.00Hz
DRV▶ Cmd. freq
00 0.00Hz
DRV▶ Cmd. freq
00 60.00Hz
DRV▶T/K 5.0 A
00 FWD 60.00Hz
Note) To enable Run/Stop via keypad & Freq setting via control terminal…
Setting: DRV-03 [Drive Mode (Run/Stop method)] = Keypad
DRV-04 [Frequency Mode (Freq. setting method)] = V1, V1S or I
