APPENDIX C- RELATED PARAMETERS
Use Related parameter codes
Accel/Decel time, Pattern Adjustment
DRV-01 [Acceleration Time], DRV-02 [Deceleration Time],
FU1-02 [Acceleration Pattern], FU1-03 [Deceleration Pattern]
Reverse Rotation Prevention FU1-01 [Forward/Reverse Prevention]
Accel/Decel at Continuous Rating Range FU1-02 [Acceleration Pattern], FU1-03 [Deceleration Pattern]
Braking Operation Adjustment
FU1-20 [Starting Mode], FU1-21~22 [DC Injection Braking
at Starting]
FU1-23 [Stop Mode], FU1-24~27 [DC Injection Braking],
Operations at freq. Over 60 Hz
FU1-30 [Max. Frequency],
FU1-35 [Frequency High Limit],
I/O-05 [Frequency Corresponding to V1 Max Voltage],
I/O-10 [Frequency Corresponding to I Max Current],
I/O-16 [Frequency Corresponding to I Max Pulse]
Selecting an Appropriate Output
Characteristics for the Load
FU1-30 [Max. Frequency], FU1-31 [Base Frequency]
Motor Output Torque Adjustment
FU1-32 [Starting Frequency],
FU1-70~71[Stall Prevention],
FU2-67~69 [Torque Boost],
FU2-40 [Motor Rating]
Output Frequency Limit
FU1-33~35[Frequency High/Low Limit],
I/O-01~16 [Analog Frequency Setting]
Motor Overheat Protection
FU1-60~62 [Electronic Thermal], FU2-40 [Motor Rating]
I/O-97, 98 [External Thermal Sensor]
Multi-step Operation
I/O-20~27 [Programmable Digital Input Define],
DRV-00, 05~07,I/O-31~42 [Multi-step Frequency],
FU1-34~35 [Frequency High/Low Limit]
Jog Operation I/O-30 [Jog Frequency]
Frequency Jump Operation FU2-10~16 [Frequency Jump]
Electronic Brake Operation Timing
I/O-74~75 [Frequency Detection], I/O-76~79 [Programmable
Digital Output Define]
Rotating Speed Display DRV-09 [Motor Rpm], FU2-47 [Motor Rpm Display Gain]
Function Change Prevention FU2-94 [Parameter Lock]
Energy Saving FU1-51~52 [Energy Saving]
Auto Restart Operation after Alarm Stop FU2-20~21 [Auto Restart]
2
nd
Motor Operation APP-20~29 [2
nd
Function]
PID Feedback Operation APP-02~17 [PID Operation]
Adjusting Frequency Reference/Output I/O-01~16 [Analog Frequency Setting]
Commercial Line<-> Inverter Switchover
I/O-20~27 [Programmable Digital Input Terminal],
I/O-76~79 [Programmable Digital Output Terminal]
Frequency Meter Calibration I/O-70~73 [S0/S1 Analog Output]
Operation via Communication with a PC
I/O-90 [Inverter Number], I/O-91 [Communication Speed],
I/O-92~93 [Lost Command]
