3.2.3 Wires and terminal lugs
Refer to below for wires, terminal lugs, and screws used to connect the inverter power input and output.
Wire size
Screw torque
R(L1), S(L2), T(L3) U, V, W
Inverter capacity
Terminal
screw
size
kgf · cm lb · in
mm
2
AWG or
kcmil
mm
2
AWG or
kcmil
5.5kW(7.5HP)
M4 7.1 ~ 12.2 6.2~10.6 5.5 10 5.5 10
7.5kW(10HP)
M5 8 8 8 8
11kW(15HP)
M5
24.5 ~ 31.8 21.2~27.6
14
6 14 6
15kW(20HP)
M6 22 4 22 4
18.5kW(25HP)
M6
30.6 ~ 38.2 26.6~33.2
38
2 38 2
22kW(30HP)
M8 38 2 38 2
2
0
0
V
30kW(40HP)
M8
61.2 ~ 91.8 53.1~79.7
60
1/0 60 1/0
5.5kW(7.5HP)
M4 3.5 12 3.5 12
7.5Kw(10HP)
M4 3.5 12 3.5 12
11 kW(15HP)
M4
7.1 ~ 12.2 6.2~10.6
5.5
10 5.5 10
15 kW(20HP)
M6 8 8 8 8
18.5kW(25HP)
M6
30.6~38.2 26.6~33.2
14
6 14 6
22~30kW
(30~40HP)
M8 61.2~91.8 53.1~79.7 22 4 22 4
37~55kW
(50~75HP)
M8 67.3~87.5 58.4~75.9 38 2 38 2
75~90kW
(100~125HP)
M10 89.7~122.0 77.9~105.9 60 1/0 60 1/0
110~132Kw
(150~200HP)
M12 100 4/0 100 4/0
160kW(250HP)
M12 150 300 150 300
220kW(300HP)
M12
182.4~215.0 158.3~186.6
200
400 200 400
280kW(350HP)
M12 250 500 250 500
315kW(400HP)
M12 325 700 325 700
375kW(500HP)
M12 2×200
2×400 2×200 2×400
4
0
0
V
450kW(600HP)
M12
182.4~215.0 158.3~186.6
2×250
2×500 2×250 2×500
* Apply the rated torque to terminal screws.
* Loose screws can cause of short circuit or malfunction. Tightening the screw too much can damage the terminals and
cause a short circuit or malfunction.
* Use copper wires only with 600V, 75℃ ratings.
For 7.5~11kW 240V type inverters, R(L1), S(L2), T(L3) and U, V, W
terminals are only for use with insulated ring type connector.
