LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-20
[COM GROUP]
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
COM-00 9600 Jump Code
Jump code
1 to 60 1 O
COM-01 9601 Type of SUB Board
Opt B/D
RS485
DeviceNet
ProfiBus
Bacnet
Lonwork
* *
COM-02 9602 Option Mode
Opt mode
None
Command
Freq
Cmd + Freq
None X
COM-03 9603 Option Version
Opt Version
Ver X.X Ver X.X *
COM-13 960D DeviceNet Input Instance In Instance
(70)
(71)
(110)
(111)
70
○
COM-17 9611 PLC Option Station ID Station ID 0 - 63 1
○
COM-20 9614 Profibus ID Profi MAC ID 1 - 127 1
○
COM-30 961E Output Number Output Num 0 - 8 3
○
COM-31 961F Output1 Output 1 0000 – FFFF (HEX) 000A(HEX)
○
COM-32 9620 Output2 Output 2 0000 – FFFF (HEX) 000E(HEX)
○
COM-33 9621 Output 3 Output 3 0000 – FFFF (HEX) 000F(HEX)
○
COM-34 9622 Output 4 Output 4 0000 – FFFF (HEX) 0000(HEX)
○
COM-35 9623 Output 5 Output 5 0000 – FFFF (HEX) 0000(HEX)
○
COM-36 9624 Output 6 Output 6 0000 – FFFF (HEX) 0000(HEX)
○
COM-37 9625 Output 7 Output 7 0000 – FFFF (HEX) 0000(HEX)
○
COM-38 9626 Output 8 Output 8 0000 – FFFF (HEX) 0000(HEX)
○
COM-40 9628 Input Number Input Num 0 - 8 2
○
COM-41 9629 Input 1 Input 1 0000 – FFFF (HEX) 0005(HEX)
○
COM-42 962A Input 2 Input 2 0000 – FFFF (HEX) 0006(HEX)
○
COM-43 962B Input 3 Input 3 0000 – FFFF (HEX) 0000(HEX)
○
COM-44 962C Input 4 Input 4 0000 – FFFF (HEX) 0000(HEX)
○
COM-45 962D Input 5 Input 5 0000 – FFFF (HEX) 0000(HEX)
○
COM-46 962E Input 6 Input 6 0000 – FFFF (HEX) 0000(HEX)
○
COM-47 962F Input 7 Input 7 0000 – FFFF (HEX) 0000(HEX)
○
COM-48 9630 Input 8 Input 8 0000 – FFFF (HEX) 0000(HEX)
○
COM-60 963C Parity Selection Parity/Stop
8None/1Stop
8None/2Stop
8Even/1Stop
8 Odd/1Stop
8None/1Stop
○
COM-61
(32)
963D
Communication Option
Common Pararmeter 1
Opt Para-1 0000 – FFFF (HEX) 0000(HEX)
○
COM-62 963E
Communication Option
Common Pararmeter 2
Opt Para-2 0000 – FFFF (HEX) 0000(HEX)
○
COM-63 963F
Communication Option
Common Pararmeter 3
Opt Para-3 0000 – FFFF (HEX) 0000(HEX)
○
COM-64 9640
Communication Option
Common Pararmeter 4
Opt Para-4 0000 – FFFF (HEX) 0000(HEX)
○
COM-65 9641
Communication Option
Common Pararmeter 5
Opt Para-5 0000 – FFFF (HEX) 0000(HEX)
○
COM-66 9642
Communication Option
Common Pararmeter 6
Opt Para-6 0000 – FFFF (HEX) 0000(HEX)
○
COM-67 9643
Communication Option
Pararmeter Update
Comm UpDate
1 (No)
2 (Yes)
1 (No) X
Refer to
the
correspo-
nding
option
manual
* Only the above COM group displayed when the corresponding option board is installed.
* Refer to the communcaion option manual for details.
* Lonwork and Backnet communication will be available later.
