Chapter 5 – Parameter list
5-15
[APP GROUP]
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
APP-00 9700 Jump to Desired Code # Jump code
1 to 99
(LCD Keypad Only)
1 O 6-56
APP-01
(24)
9701 Application Mode Selection App mode
0 (None)
1 (MMC)
0 (None) X
6-56
APP-02 9702 PID Operation Selection Proc PI mode
0 (No)
1 (Yes)
0 (No) X 6-56
APP-03
(25)
9703 PID F Gain Selection PID F-gain 0 to 999.9[%] 0.0 [%] O 6-61
APP-04
(256
9704
PID Auxiliary Reference
Mode Selection
Aux Ref Mode
0 (No)
1 (Yes)
0 (No) X 6-61
APP-05
(27)
9705
PID Auxiliary Reference
Signal Selection
Aux Ref Sel
0 (Keypad-1)
1 (Keypad-2)
2 (V1)
3 (V1S)
4 (I)
5 (V1+I)
6 (Pulse)
7 (Int. 485)
8 (Ext. PID)
2 (V1) X 6-61
APP-06 9706
PID Feedback Signal
Selection
PID F/B
0 (I)
1 (V1)
2 (Pulse)
0 (I) X 6-61
APP-07 9707 P Gain for PID Control PID P-gain 0 to 999.9 [%] 1.0 [%] O 6-61
APP-08 9708 I Gain for PID Control PID I-time 0 to 32.0 [sec] 10.0 [sec] O 6-61
APP-09 9709 D Gain for PID Control PID D-time 0 to100 [msec] 0.0 [msec] O 6-61
APP-10 970A
High Limit Frequency for
PID Control
PID limit-H 0.00 to FU1-30 60 .00[Hz] O 6-61
APP-11 970B
Low Limit Frequency for
PID Control
PID limit-L
FU1-32
to APP-10
0.5 [Hz] O 6-61
APP-12 970C PID Output Scale PID Out Scale 0.0 to 999.9 [%] 100.0 [%] X 6-62
APP-13 970D PID P2 Gain PID P2-gain 0.0 to 999.9 [%] 100.0 [%] X 6-62
APP-14 970E P Gain Scale P-gain Scale 0.0 to 100.0 [%] 100.0 [%] X
APP-15 960F PID Output Inverse Out inverse
0 (No)
1 (Yes)
0 (No) X
APP-17 9711 PID U curve feedback select PID U Fbk
0 (No)
1 (Yes)
0 (No) X
6-62
APP-20
(28)
9714 2nd Acceleration Time 2nd Acc time 0 to 6000 [sec] 5 [sec] O
APP-21 9715 2nd Deceleration Time 2nd Dec time 0 to 6000 [sec] 10 [sec] O
APP-22 9716 2nd Base Frequency 2nd BaseFreq 30 to FU1-30 [Hz] 60 [Hz] X
APP-23 9717 2nd V/F Pattern 2nd V/F
0 (Linear)
1 (Square)
2 (User V/F)
0 (Linear) X
APP-24 9718 2nd Forward Torque Boost 2nd F-boost 0 to 15 [%] 2 [%] X
APP-25 9719 2nd Reverse Torque Boost 2nd R-boost 0 to 15 [%] 2 [%] X
APP-26 971A 2nd Stall Prevention Level 2nd Stall 30 to 150 [%] 100 [%] X
6-62
