LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-14
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
1 (Run Fan)
I/O-84
9454
Fan Con Sel (37 ~ 90kW) Fan Mode
2 (Temper-Fan)
0 X 6-52
I/O-85
9455
Fan Temp (37 ~ 90kW) Fan Temper
0 to 70 [℃] 70 [℃]
O 6-52
I/O-86
9456
Voltage Input
User Unit Selection
V1 Unit Sel
0 (Speed) 1 (Percent)
2 (Bar) 3 (mBar)
4 (kPa) 5 (Pa)
0 (Speed) X
I/O-87
9457
Current Input
User Unit Selection
I Unit Sel Same as I/O-86 0 (Speed) X
I/O-88
9458
Pulse Input
User Unit Selection
PulseUnitSel Same as I/O-86 0 (Speed) X
6-52
I/O-90
945A
Inverter Number Inv No. 1 to 250 1 O
0 (1200 bps)
1 (2400 bps)
2 (4800 bps)
3 (9600 bps)
4 (19200 bps)
I/O-91
(22)
945B
Baud Rate Selection Baud rate
5 (38400 bps)
3 (9600 bps) O
6-53
0 (None)
1 (FreeRun)
I/O-92
(23)
945C
Operating method
at loss of freq. reference
COM Lost Cmd
2 (Stop)
0 (None) O
I/O-93 945D
Waiting time after loss of
freq. reference
COM Time Out 0.1 to 120 [sec] 1.0 [sec] O
6-53
I/O-94 945E
Communication Response
Delay time
Delay Time 2 to 1000 [msec] 5 [msec] O 6-53
I/O-95 945F A or B contact In No/Nc Set
00000000000
/11111111111
00000000000 X
6-53
I/O-96 9460 Input time In CheckTime 1 to 1000 1 [msec] X 6-54
I/0-97 9461 Overheat trip selection OH Trip sel 000 to 111 [bit] 010 [bit] X
I/0-98 9462
Motor overheat trip
temperature
MO Trip Temp 0 to 255 [8C] 110 [8C] X
6-54
* The gray-highlighted codes are hidden parameters and will appear when the related functions are to be set.
(17) When DRV-04 is set to either V1, V1S, I or V1+I or Pulse, only selected item codes are displayed in I/O-1~I/O-
19.
(18) Only user unit displayed when APP-02 or APP-80 is set to [Yes], after APP-06 is set to one of I, V, Pulse, after
then one of I/O-86 ~I/O-88 is set to either speed, percentage, Bar, mBar, kPa, Pa..
(19) I/O-30 ~ I/O-34 displayed only when one of I/O-20 ~ I/O-27 is set to either JOG, Speed_L, Speed_M, Speed_H.
I/O-35 ~ I/O-42 displayed only when one of I/O-20 ~ I/O-27 is set to Speed_X.
(20) I/O-52 ~ I/O-63 displayed only when one of I/O-20 ~ I/O-27 is set to either XCEL_L, XCEL_M, XCEL_H.
(21) I/O-74 ~ I/O-75 displayed only when one of I/O-76 ~ I/O-79 is set to either FDT-1~FDT5
(22) 38400 bps can be set only when the external communication option card is installed.
(23) Only I/O-92 ~ I/O-93 displayed when DRV-03/04 is set to [int485].
