LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-13
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
I/O-71 9447 S0 output adjustment S0 adjust 10 to 200 [%] 100 [%] O
I/O-72
9448
S1 output selection S1 mode Same as I/O-70 2 (Voltage) O
I/O-73
9449
S1 output adjustment S1 adjust 10 to 200 [%] 100 [%] O
6-47
I/O-74
(21)
944A
Frequency Detection Level
FDT freq 0 to FU1-30 [Hz] 30 [Hz] O 6-47
I/O-75
944B
Frequency Detection
Bandwidth
FDT band 0 to FU1-30 [Hz] 10 [Hz] O 6-47
I/O-76
944C
Programmable Digital
Output Terminal Define
(Aux terminal)
Aux mode1
0 (NONE)
1 (FDT-1)
2 (FDT-2)
3 (FDT-3)
4 (FDT-4)
5 (FDT-5)
6 (OL)
7 (IOL)
8 (Stall)
9 (OV)
10 (LV)
11 (OH)
12 (Lost Command)
13 (Run)
14 (Stop)
15 (Steady)
16 (INV line)
17 (COMM line)
18 (SSearch)
19 (Ready)
20 (MMC)
0 (NONE) O
I/O-77
944D
Programmable Digital
Output Terminal Define
Aux mode2 Same as I/O-76 0 (NONE) O
I/O-78
944E
Programmable Digital
Output Terminal Define
Aux mode3 Same as I/O-76 0 (NONE) O
I/O-79
944F
Programmable Digital
Output Terminal Define
Aux mode4 Same as I/O-76 0 (NONE) O
6-48
I/O-80
9450
Fault Output Relay Setting
(3A, 3B, 3C)
Relay mode 000 to 111 [bit] 010 [bit] O
6-51
I/O-81
9451
Terminal Output Status Out status 00000000/11111111 00000000 * 6-52
I/O-82
9452
Waiting time after Fault
Output Relay On
Relay On 0 to 9999 0 X
I/O-83
9453
Waiting time after Fault
Output Relay Off
Relay Off 0 to 9999 0 X
6-52
I/O-84
9454
Fan Con Sel (37 ~ 90kW) Fan Mode 0 (Power On Fan) 0 X 6-52
