Chapter 5 – Parameter list

5-12

CODE

Comm.

Addr

Description

LCD Keypad

Display

Setting Range

Factory

Default

Adj.

During

Run

Page

I/O-26 941A

Programmable Digital Input

Terminal ‘M7’ Define

M7 define Same as I/O-20 30 (FX) O

I/O-27 941B

Programmable Digital Input

Terminal ‘M8’ Define

M8 define Same as I/O-20 31 (RX) O

I/O-28 941C Terminal Input Status In status

00000000000

/11111111111

00000000000 *

I/O-29 941D

Filtering Time Constant for

Programmable Digital Input

Terminals

Ti Filt Num 2 to 1000 [msec] 15 O

6-41

I/O-30

(19)

941E Jog Frequency Setting Jog freq 10 [Hz] O

I/O-31 941F Step Frequency 4 Step freq-4 40 [Hz] O

I/O-32 9420 Step Frequency 5 Step freq-5 50 [Hz] O

I/O-33 9421 Step Frequency 6 Step freq-6 40 [Hz] O

I/O-34 9422 Step Frequency 7 Step freq-7 30 [Hz] O

I/O-35 9423 Step Frequency 8 Step freq-8 20 [Hz] O

I/O-36 9424 Step Frequency 9 Step freq-9 10 [Hz] O

I/O-37 9425 Step Frequency 10 Step freq-10 20 [Hz] O

I/O-38 9426 Step Frequency 11 Step freq-11 30 [Hz] O

I/O-39 9427 Step Frequency 12 Step freq-12 40 [Hz] O

I/O-40 9428 Step Frequency 13 Step freq-13 50 [Hz] O

I/O-41 9429 Step Frequency 14 Step freq-14 40 [Hz] O

I/O-42 942A Step Frequency 15 Step freq-15

0 to FU1-30

30 [Hz] O

6-42

I/O-50 9432

Acceleration Time 1

(for Step speed)

Acc time-1 0 to 6000 [sec] 20 [sec] O

I/O-51 9433

Deceleration Time 1

(for Step speed)

Dec time-1 0 to 6000 [sec] 20 [sec] O

I/O-52

(20)

9434

Acceleration Time 1

(for Step speed)

Acc time-2 0 to 6000 [sec] 30 [sec] O

I/O-53 9435 Deceleration Time 2 Dec time-2 0 to 6000 [sec] 30 [sec] O

I/O-54 9436 Acceleration Time 3 Acc time-3 0 to 6000 [sec] 40 [sec] O

I/O-55 9437 Deceleration Time 3 Dec time-3 0 to 6000 [sec] 40 [sec] O

I/O-56 9438 Acceleration Time 4 Acc time-4 0 to 6000 [sec] 50 [sec] O

I/O-57 9439 Deceleration Time 4 Dec time-4 0 to 6000 [sec] 50 [sec] O

I/O-58 943A Acceleration Time 5 Acc time-5 0 to 6000 [sec] 40 [sec] O

I/O-59 943B Deceleration Time 5 Dec time-5 0 to 6000 [sec] 40 [sec] O

I/O-60 943C Acceleration Time 6 Acc time-6 0 to 6000 [sec] 30 [sec] O

I/O-61 943D Deceleration Time 6 Dec time-6 0 to 6000 [sec] 30 [sec] O

I/O-62 943E Acceleration Time 7 Acc time-7 0 to 6000 [sec] 20 [sec] O

I/O-63 943F Deceleration Time 7 Dec time-7 0 to 6000 [sec] 20 [sec] O

6-44

0 (Frequency)

1 (Current)

2 (Voltage)

3 (DC link Vtg)

I/O-70 9446 S0 output selection S0 mode

4 (Ext PID Out)

(Frequency)

O 6-47
