LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-11
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
I/O-20
9414
Programmable Digital Input
Terminal ‘M1’ Define
M1 define
0 (Speed-L)
1 (Speed-M)
2 (Speed-H)
3 (XCEL-L)
4 (XCEL-M)
5 (XCEL-H)
6 (Dc-brake)
7 (2nd Func)
8 (Exchange)
9 (- Reserved -)
10 ( Up)
11 (Down)
12 (3-Wire)
13 (Ext Trip)
14 (Pre-Heat)
15 (iTerm Clear)
16 (Open-loop)
17 (LOC/REM)
18 (Analog hold)
19 (XCEL stop)
20 (P Gain2)
21 (- Reserved -)
22 (Interlock1)
23 (Interlock2)
24 (Interlock3)
25 (Interlock4)
26 (Speed_X)
27 (RST)
28 (BX)
29 (JOG)
30 (FX)
31 (RX)
32 (ANA_CHG)
33 (Pre-Excite)
34 (Ext PID Run)
0 (Speed-L) O
I/O-21 9415
Programmable Digital Input
Terminal ‘M2’ Define
M2 define Same as I/O-20 1 (Speed-M) O
I/O-22 9416
Programmable Digital Input
Terminal ‘M3’ Define
M3 define Same as I/O-20 2 (Speed-H) O
I/O-23 9417
Programmable Digital Input
Terminal ‘M4’ Define
M4 define Same as I/O-20 27 (RST) O
I/O-24 9418
Programmable Digital Input
Terminal ‘M5’ Define
M5 define Same as I/O-20 28 ( BX ) O
I/O-25 9419
Programmable Digital Input
Terminal ‘M6’ Define
M6 define Same as I/O-20 29 (JOG) O
6-41
