Chapter 5 – Parameter list
5-4
[FU1 GROUP]
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
FU1-00 9200 Jump to Desired Code # Jump code
1 to 74
(Use Only LCD
Keypad)
1 O 6-10
0 (None)
1 (Fwd prev)
FU1-01 9201 Run Prevention Run prevention
2 (Rev prev)
0 (None) X 6-10
0 (Linear)
1 (S-curve)
FU1-02 9202 Acceleration Pattern Acc. Pattern
2 (U-curve)
0 (Linear) X 6-10
0 (Linear)
1 (S-curve)
FU1-03 9203 Deceleration Pattern Dec. Pattern
2 (U-curve)
0 (Linear) X 6-10
FU1-04
(5)
9204
Start Curve for S-Curve
Accel/Decel Pattern
Start Curve 0 to 100 [%] 50 [%] X
FU1-05 9205
End Curve for S-Curve
Accel/Decel Pattern
End Curve 0 to 100 [%] 50 [%] X
6-10
0(No)
FU1-10 920A Pre-Heat Pre-Heat mode
1(Yes)
0 (No) X
FU1-11 920B Pre-Heat Value Pre Heat level 1 to 50 [%] 30 (%) X
FU1-12 920C Pre-Heat Duty Pre Heat Perc 1 to 100 [%] 100 (%) X
6-11
0 (Accel)
1 (Dc-start)
FU1-20 9214 Start Mode Start mode
2 (Flying-start)
0 (Accel) X 6-12
FU1-21
(6)
9115
Starting DC Injection
Braking Time
DcSt time 0 to 60 [sec] 0 [sec] X
FU1-22 9116
Starting DC Injection
Braking Value
DcSt value 0 to 150 [%] 50 [%] X
6-12
0 (Decel)
1 (Dc-brake)
2 (Free-run)
FU1-23 9217 Stop Mode Stop mode
3 (Flux-brake)
0 (Decel) X 6-13
FU1-24
(7)
9218
DC Injection Braking
On-delay Time
DcBlk time 0.1 to 60 [sec] 0.1 [sec] X
FU1-25 9219
DC Injection Braking
Frequency
DcBr freq 0.1 to 60 [Hz] 5 [Hz] X
FU1-26 921A
DC Injection Braking
Time
DcBr time 0 to 60 [sec] 1 [sec] X
FU1-27 921B DC Injection Braking Value DcBr value 0 to 200 [%] 50 [%] X
6-14
0(No)
FU1-28 921C Safety Stop Safety Stop
1(Yes)
0 (No) X 6-14
FU1-29 921D Power Source Freq Line Freq 40 to 120 [Hz] 60 [Hz] X 6-15
FU1-30 921E Maximum Frequency Max freq 40 to 120 [Hz] 60 [Hz] X 6-15
FU1-31 921F Base Frequency Base freq 30 to 120 [Hz] 60 [Hz] X 6-15
FU1-32 9220 Starting Frequency Start freq 0.1 to 10 [Hz] 0.5 [Hz] X 6-15
0(No)
FU1-33 9221 Frequency Limit selection Freq limit
1(Yes)
0 (No) X 6-16
To Next Page
