Chapter 5 – Parameter list
5-3
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
* The gray-highlighted codes are hidden parameters and will appear when the related functions are to be set.
(1) The speed unit is changed from [Hz] to [%] when DRV-16 is set to [Rpm]. Only User Unit will be displayed when
APP-02 is set to [Yes] and when APP-06 is set to either I, V1 or Pulse and when one of I/O-86~ I/O-88 is set to
either [Speed], [Percent], [Bar], [mBar], [kPa] or [Pa].
Output Frequency is displayed in DRV-00 during the Inverter is running.
User Unit reference is displayed in DRV-00 during the Inverter is not running.
(2) DRV-15, DRV-18 will appear when APP-02 [Process PI Mode] is set to “Yes”. Also User Unit is displayed when
one of I/O-86~ I/O-88 is set to either [Speed], [Percent], [Bar], [mBar], [kPa] or [Pa].
(3)DRV-20 will appear when APP-80 [ExtProcess PI Mode] is set to “Yes”.
(4) DRV-91/92 will appear only when one of I/O-20~27 is set to [Main drv] and DRV-03/04 is set to [int485].
