LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-5
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
FU1-34
(8)
9222 Low Limit Frequency F-limit Lo FU1-32 to FU1-35 0.5 [Hz] O
FU1-35 9223 High Limit Frequency F-limit Hi
FU1-34
to FU1-30
60 [Hz] X
6-16
0 (Linear)
1 (Square)
FU1-40 9228 Volts/Hz Pattern V/F pattern
2 (User V/F)
0 (Linear) X 6-16
FU1-41
(9)
9229 User V/F – Frequency 1 User freq 1 0 to FU1-30 15 [Hz] X
FU1-42 922A User V/F – Voltage 1 User volt 1 0 to 100 [%] 25 [%] X
FU1-43 922B User V/F – Frequency 2 User freq 2 0 to FU1-30 30 [Hz] X
FU1-44 922C User V/F – Voltage 2 User volt 2 0 to 100 [%] 50 [%] X
FU1-45 922D User V/F – Frequency 3 User freq 3 0 to FU1-30 45 [Hz] X
FU1-46 922E User V/F – Voltage 3 User volt 3 0 to 100 [%] 75 [%] X
FU1-47 922F User V/F – Frequency 4 User freq 4 0 to FU1-30 60 [Hz] X
FU1-48 9230 User V/F – Voltage 4 User volt 4 0 to 100 [%] 100[%] X
6-17
FU1-49 9231 Input voltage adjustment VAC 440.0V 73 to 115.0 [%] 100.0 [%] X 6-17
FU1-50 9232 Motor Rated Voltage Motor Volt 0 to 600 [V] 0 [V] X 6-17
0 (None)
1 (Manual)
FU1-51 9233 Energy Save Energy save
2(Auto)
0 (None) X
FU1-52
(10)
9234 Energy Save % Manual save% 0 to 30 [%] 0 [%] O
6-18
FU1-54 9236 Integrating Wattmeter KiloWattHour M kWh * X 6-18
FU1-55 9237 Inverter Temperature Inv. Temp. 0 to 160 [degree] * X 6-18
FU1-56 9238 Motor Temperature Motor Temp. 0 to 160 [degree] * X 6-18
0(No)
FU1-57 9239 No Motor Selection No Motor Sel
1(Yes)
1 [Yes] X 6-18
FU1-58 923A Trip Current Level No Motor Level 5 to 100 [%] 5 [%] X 6-18
FU1-59 923B Trip Time Setting No Motor Time 0.5 to 10.0 [sec] 3.0 [sec] X 6-18
0(No)
FU1-60 923C Electronic Thermal Selection ETH select
1(Yes)
1 (Yes) O 6-19
FU1-61 923D
Electronic Thermal Level for
1 Minute
ETH 1min FU1-62 to 200 [%] 150 [%] O 6-19
FU1-62 923E
Electronic Thermal Level for
Continuous
ETH cont
50 to FU1-61
(Maximum 150%))
120 [%] O
6-19
FU1-63 923F
Characteristic Selection
(Motor Type)
Motor type
0 (Self-cool)
1 (Forced-cool)
0 (Self-cool) O 6-19
FU1-64 9240 Overload Warning Level OL level 30 to 110 [%] 110 [%] O 6-20
FU1-65 9241 Overload Warning Time OL time 0 to 30 [sec] 10 [sec] O 6-20
0 (No)
FU1-66 9242 Overload Trip Selection OLT select
1(Yes)
0 (No) O 6-21
FU1-67
(11)
9243 Overload Trip Level OLT level 30 to 150 [%] 120[%] O 6-21
FU1-68 9244 Overload Trip Delay Time OLT time 0 to 60 [sec] 60 [sec] O 6-21
FU1-69 9245
Input/Output Phase Loss
Protection
Trip select 000 to 111 (Bit Set) 100 O
6-21
FU1-70 9246
Stall Prevention Mode
Selection
Stall prev. 000 to 111(Bit) 000(Bit) X
6-21
5.5~280kW 30 to 150 [%]
FU1-71 9247
Stall
Prevention
Level
315~450kW
Stall level
30 to 120 [%]
100[%] X
6-21
FU1-72 9248
Accel/Decel Change
Frequency
Acc/Dec ch F 0 to FU1-30 0 [Hz] X
6-22
0 (Max freq)
FU1-73 9249
Reference Frequency for
Accel and Decel
Acc/Dec freq
1 (Delta freq)
0 (Max freq) X 6-23
