LSIS sv-ip5a User Manual

Chapter 5 – Parameter list
5-9
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
933F
Leakage Inductance of Motor Lsigma
0 to (depending on
FU2-40) [mH]
* Depending
on FU2-40
X
6-32
FU2-63
* Automatically set corresponding to motor rating. If different, check the motor rating setting.
FU2-64
(16)
9340
Pre-excitation Time PreEx time 0 to 60 [sec] 1 [sec] X 6-32
FU2-65
9341
P Gain for
Sensorless Control
SL P-gain 0 to 9999 1000 O 6-33
FU2-66
9342
I Gain for Sensorless Control SL I-gain 0 to 9999 100 O 6-33
0 (Manual)
FU2-67
9343
Manual/Auto Torque Boost
Selection
Torque boost
1(Auto)
0 (Manual) X
5.5~90kW 2.0 [%]
FU2-68
9344
Torque Boost
in Forward
Direction
110~450kW
Fwd boost 0 to 15 [%]
1.0 [%]
X
5.5~90kW 2.0 [%]
FU2-69
9345
Torque Boost
in Reverse
Direction
110~450kW
Rev boost 0 to 15 [%]
1.0 [%]
X
6-33
FU2-80
9350
Power On display PowerOn disp 0 to 12 0 O
6-34
0 (Voltage)
FU2-81
9351
User Display Selection User disp
1 (Watt)
0 (Voltage) O
6-34
FU2-82
9352
Software Version S/W Version Ver X.XX Ver X.XX *
6-35
FU2-83
9353
Last Trip Time LastTripTime X:XX:XX:XX:XX:X X
FU2-84
9354
Power On Time On-time X:XX:XX:XX:XX:X X
FU2-85
9355
Run-time Run-time X:XX:XX:XX:XX:X X
6-35
FU2-87
9357
Power Set PowerSet 0.1~400 % 100 O
6-35
0 (Default)
1 (All Para)
FU2-90
935A
Parameter Display Para. disp
2 (Diff Para)
0 (Default) X
6-35
0(No)
FU2-91
935B
Read Parameter Para. Read
1(Yes)
0 (No) X
6-35
0(No)
FU2-92
935C
Write Parameter Para. Write
1(Yes)
0 (No) X
6-35
FU2-93
935D
Initialize Parameters Para. init
0 (No) 1 (All Groups)
2 (DRV) 3 (FU1)
4 (FU2) 5 (I/O)
6 (EXT) 7 (COM)
8 (APP)
0 (No) X
6-36
FU2-94
935E
Parameter Write Protection Para. Lock 0 to 9999 0 O 6-36
0(No)
FU2-95
935F
Parameter Save Para. save
1(Yes)
0 (No) X 6-36
* The gray-highlighted codes are hidden parameters and will appear when the related functions are to be set.
(12) Only displayed when FU2-07 is set to [1~10 sec].
(13) Only displayed when FU2-10 is set to [Yes].
(14) Only FU2-23~24 displayed when FU2-22 [Speed search] is set to [0001~1111]. Also displayed when FU1-20 is
‘Flying Start’.
(15) Only displayed when FU2-25 [Retry number] is set to [1~10].
(16) Only FU2-64~66 displayed when FU2-60 is set to [Sensorless].
