Chapter 5 – Parameter list
5-8
CODE
Comm.
Addr
Description
LCD Keypad
Display
Setting Range
Factory
Default
Adj.
During
Run
Page
Rated Motor Selection
for 5.5 ~ 450kW
Inverter
Motor select
0 (0.75kW)
1 (1.5kW)
2 (2.2kW)
3 (3.7kW)
4 (5.5kW/)
5 (7.5kW/)
6 (11.0kW)
7 (15.0kW)
8 (18.5kW)
9 (22.0kW)
10 (30.0kW)
11 (37.0kW)
12 (45.0kW)
13 (55.0kW)
14 (75.0kW)
15 (90.0kW)
16 (110.0kW)
17 (132.0 kW)
18 (160.0 kW)
18 (220.0 kW)
20 (280.0 kW)
21 (315.0 kW)
22 (375.0 kW)
23 (450.0 kW)
* Depending
on the
inverter
capacity
X
6-28
FU2-40
9328
* A motor rating same as inverter capacity is automatically set. If different, set the correct value.
FU2-41 9329 Number of Motor Poles Pole number 2 to 12 4 X 6-28
FU2-42 932A Rated Motor Slip Rated-Slip 0 to 10 [Hz] X
FU2-43 932B
Rated Motor Current
(RMS)
Rated-Curr 1 to 999.9 [A] X
FU2-44 932C
No Load Motor Current
(RMS)
Noload-Curr 0.5 to 999.9 [A] X
FU2-45 932D Motor Efficiency Efficiency 70 to 100 [%]
* Depending
on FU2-40
X
FU2-46 932E Load Inertia Inertia rate 0 to 8 0 X
FU2-47 932F
Gain for Motor Speed
Display
RPM factor 1 to 1000 [%] 100 [%] O
6-28
5.5~22kW
0.7~15
[kHz]
30kW
0.7~ 10
[kHz]
5.0 [kHz]
37~75kW
0.7 ~ 4
[kHz]
4.0 [kHz]
90~280kW
0.7 ~ 3
[kHz]
3.0 [kHz]
FU2-48
9330
Carrier Frequency Carrier freq
315~450kW
0.7 ~ 2
[kHz]
2.0 [kHz]
O
6-29
0 (Normal 1)
1 (Normal 2)
FU2-49
9331
PWM Type Selection PWM Mode
2 (Low leakage)
0 (Normal 1) X
6-30
0(V/F)
1 (Slip compen)
FU2-60
933C
Control Mode Selection Control mode
2 (Sensorless)
0 (V/F) X
6-30
0 (No)
FU2-61
933D
Auto Tuning Selection Auto tuning
1 (Yes)
0 (No) X
FU2-62
933E
Stator Resistance of Motor Rs
0 to (depending on
FU2-40) [ohm]
* Depending
on FU2-40
X
6-32
