Chapter 6 - Parameter Description [APP]
6-71
APP –82 [Ext PID Ref value] is settable when APP-
81 [Ext PID Ref selection] is set to “Keypad”.
APP–97 [Ext PID Loop Time] sets the time to
activate Ext PID controller. Set the desired value
according to system.
Ext PID can be used for ①controlling other system
independently as an external PID controller ②using
both PID controller in APP-02 and External PID
controller ③using Ext PID output as an Inverter
target frequency. See 10) APP-02, APP-80 (to use
Dual PID operation) for more details.
