iP5A series / Footprint Filters
INVERTER POWER CODE CURRENT VOLTAGE
LEAKAGE
CURRENT
DIMENSIONS
L W H
MOUNTING
Y X
WEIGHT MOUNT
OUTPUT
CHOKES
THREE PHASE NOM. MAX.
SV055iP5A-2 5.5kW FFP5-T030-(x) 30A 250VAC 0.3mA 18mA 329x149.5x50 315x120 2 Kg. M5 FS – 2
SV075iP5A-2 7.5kW FFP5-T050-(x) 50A 250VAC 0.3mA 18mA 329x199.5x60 315x160 2.5 Kg. M5 FS – 2
SV110iP5A-2 11kW
SV150iP5A-2 15kW
100A 250VAC 0.3mA 18mA FS – 3
SV185iP5A-2 18kW
SV220iP5A-2 22kW
120A 250VAC 0.3mA 18mA FS – 3
SV300iP5A-2 30kW 150A 250VAC 0.3mA 18mA FS – 3
SV055iP5A-4 5.5kW FFP5-T030-(x) 30A 380VAC 0.5mA 27mA 329x149.5x50 315x120 2 Kg. M5 FS – 2
SV075iP5A-4 7.5kW FFP5-T031-(x) 31A 380VAC 0.5mA 27mA 329x199.5x60 315x160 2.5 Kg. M5 FS – 2
SV110iP5A-4 11kW FFP5-T050-(x) 50A 380VAC 0.5mA 27mA 329x199.5x60 315x160 2.5 Kg. M5 FS – 2
SV150iP5A-4 15kW
SV185iP5A-4 18kW
FFP5-T060-(x) 60A 380VAC 0.5mA 27mA 466x258x65 440.5x181 2.8 Kg. M5 FS – 2
SV220iP5A-4 22kW
SV300iP5A-4 30kW
FFP5-T070-(x) 70A 380VAC 0.5mA 27mA 541x312x65 515.5x235.3 6.1 Kg. M8 FS – 2
iP5A series / Standard Filters
INVERTER POWER CODE CURRENT VOLTAGE
LEAKAGE
CURRENT
DIMENSIONS
L W H
MOUNTING
Y X
WEIGHT MOUNT
OUTPUT
CHOKES
THREE PHASE NOM. MAX.
SV055iP5A-2 5.5kW FE-T030-( x ) 30A 250VAC 0.3mA 18mA 270x140x60 258x106 2.4 Kg. --- FS – 2
SV075iP5A-2 7.5kW FE-T050-( x ) 50A 250VAC 0.3mA 18mA 270x140x90 258x106 3.2 Kg. --- FS – 2
SV110iP5A-2 11kW
SV150iP5A-2 15kW
FE-T100-( x ) 100A 250VAC 0.3mA 18mA 420x200x130 408x166 13.8 Kg. --- FS – 3
SV185iP5A-2 18kW
SV220iP5A-2 22kW
FE-T120-( x ) 120A 250VAC 0.3mA 18mA 420x200x130 408x166 13.8 Kg. --- FS – 3
SV300iP5A-2 30kW FE-T150-( x ) 150A 250VAC 0.3mA 18mA 490x200x160 468x166 15 Kg. --- FS – 3
SV055iP5A-4 5.5kW
SV075iP5A-4 7.5kW
FE-T030-( x ) 30A 380VAC 0.5mA 27mA 270x140x60 258x106 2.4 Kg. --- FS – 2
SV110iP5A-4 11kW
SV150iP5A-4 15kW
FE-T050-( x ) 50A 380VAC 0.5mA 27mA 270x140x90 258x106 3.2 Kg. --- FS – 2
SV185iP5A-4 18kW FE-T060-( x ) 60A 380VAC 0.5mA 27mA 270x140x90 258x106 3.5 Kg. --- FS – 2
SV220iP5A-4 22kW
SV300iP5A-4 30kW
FE-T070-( x ) 70A 380VAC 0.5mA 27mA 350x180x90 338x146 7.5 Kg. --- FS – 3
SV370iP5A-4 37kW FE-T100-( x ) 100A 380VAC 1.3mA 150mA 425x200x130 408x166 13.8 Kg. --- FS – 3
SV450iP5A-4 45kW
SV550iP5A-4 55kW
FE-T120-( x ) 120A 380VAC 1.3mA 150mA 425x200x130 408x166 13.8 Kg. --- FS – 3
SV750iP5A-4 75kW FE-T170-( x ) 170A 380VAC 1.3mA 150mA 480x200x160 468x166 16 Kg. --- FS – 3
SV900iP5A-4 90kW FE-T230-( x ) 230A 380VAC 1.3mA 150mA 580x250x205 560x170 22.6 Kg. --- FS – 4
SV1100iP5A-4 110kW
SV1320iP5A-4 132kW
FE-T400-( x ) 400A 380VAC 1.3mA 150mA 392x260x116 240x235 10.3 Kg. --- FS – 4
SV1600iP5A-4 160kW
SV2200iP5A-4 220kW
FE-T600-( x ) 600A 380VAC 1.3mA 150mA 392x260x116 240x235 11 Kg. --- FS – 4
SV2800iP5A-4 280kW
SV3150iP5A-4 315kW
SV3750iP5A-4 375kW
FE-T1000-( x ) 1000A 380VAC 1.3mA 150mA 460x280x166 290x255 18 Kg. --- FS – 4
SV4500iP5A-4 450kW FE-T1600-( x ) 1600A 380VAC 1.3mA 150mA 592x300x166 340x275 27 Kg. --- FS – 4
( x ) ( 1 ) Industrial environment EN50081-2 (A class) -> EN61000-6-4:02
( 3 ) Domestic and industrial environment EN50081-1 (B class) -> EN61000-6-3:02
H
D
Y
X
W
FS SERIES ( output chokes )
CO DE D W H X Ø
FS 2 28. 5 105 62 90 5
FS 3 48 150 110 125 x 30 5
FS 4 58 200 170 180 x 45 5
Ø
