7. Product Specifications
7-40
FB Series : XML-FB01A, XML-FB02A, XML-FB04A
(The drawing in the case of Rear Type cable, it is available on request)
Name
External Dimensions
Weight(kg)
L LM LC
FB01A 109(149.2) 79(119.2) 43.5(43) 0.72(1.3)
FB02A 120(160.2) 90(130.2) 54.5(54) 0.94(1.49)
FB04A 140(180.2) 110(150.2) 74.5(74) 1.32(1.87)
NOTE 1) Use DC power (24V) to operate the brake.
