OPERATING CONTROLS AND PROCEDURES MLC650 OPERATOR MANUAL
3-70
Published 08-12-19, Control # 224-13
Figure 3-19. Load Drum Control Handles
Use this Handle for TANDEM Drums
when Both Drums are Unparked
T Appears if TANDEM Drums
are Configured and Both
Drums are Unparked
Figure 3-20. Example of Boom Point Reeving for Tandem Drums
Item Description
1 Lower Boom Point Sheaves
2 Load Block Sheaves
3 To Drum Configured for Left Side
Boom Point Sheaves
4 Left Side Boom Point Sheaves
5 To Drum Configured for Right
Side Boom Point Sheaves
6 Right Side Boom Point Sheaves
