Manitowoc MLC650 User Manual

Manitowoc Published 08-12-19, Control # 224-13_v2 4-33
MLC650 OPERATOR MANUAL SET-UP AND INSTALLATION
4
Install Drum 3
See Figure 4-26 for the following procedure:
An assist crane is required to lift the drum into position in the
rotating bed.
The assist crane must be capable of lifting 6 000kg (13,200
lb) to a height of approximately 6 m (20 ft) above the ground.
Reference Section 1 of this manual for the weights of
components.
1. Position the trailer carrying the drum in the assembly
area.
2. Attach the Manitowoc supplied lifting slings (2, View A)
to the hook of the assist crane.
3. Connect the other end of the lifting slings (2, View A) to
the lifting lugs (3) on the drum assembly (1) with the
Manitowoc supplied shackles (4).
4. Remove the tie downs and blocking securing the drum
assembly to the trailer.
5. Lift the drum assembly off the trailer and remove the
trailer.
6. Remove the safety pins and pins (7) and set aside.
7. Lift the drum into position over the rotating bed.
8. Lower the drum into the rotating bed, aligning the rear
pins (5) and the front pins (6) of the drum assembly over
the rotating bed slots. Continue to lower the drum into
the rotating bed slots.
9. Align the front holes of the drum assembly with the
rotating bed holes and insert the pins and safety pins (7).
10. Disconnect the shackles and the lifting slings (2 and 4,
View A) from the lifting lugs (3) on the drum assembly.
11. Disconnect the four hydraulic hoses (10, stored position)
from the rotating bed and connect them to the four
hydraulic couplers (9, working position) on the drum
assembly (1).
Match the identification numbers on the hoses with the
identification numbers on the couplers for proper
connection.
12. Connect the electric cable (8) from the drum assembly
(1) to the electric receptacle on the rotating bed.
