SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-188
Published 08-12-19, Control # 224-13_v2
Removing Front Platform and Ladders From
Rotating Bed and Cab
See Figure 4-145 for the following procedure:
1. Remove the quick-release pins (5) that secure the
ladders (3–4) to the platform.
NOTE: The ladders weigh approximately 20 kg (45 lb).
2. Slide the ladders off the sleeves of the platforms and set
aside.
3. Remove the cotter pins and pins (2). Remove the
platform (1). Reinsert the cotter pins and pins.
4. Prepare the platforms and ladders for shipping.
FIGURE 4-145
Item Description
1Platform
2 Cotter Pin and Pin (qty 2)
3 Upper Cab to Bed Ladder
4 Lower Cab to Bed Ladder
5 Quick Release Pin (qty 4)
To Next Page
